socomec ATyS Series Installation And Operating Manual

ATyStM - 542931D - SOCOMEC
12 EN
6. TECHNICAL DATA
RATINGS 40A 63 A 80 A 100 A 125 A 160 A
Frequencies 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Thermal current Ith at 40°C (A) 40 63 80 100 125 160
Thermal current Ith at 50°C (A) 40 63 80 100 110* 125
Thermal current Ith at 60°C (A) 40 50 63 80 100* 125
Thermal current Ith at 70°C (A) 40 40 50 63 80* 100
Rated insulation voltage Ui (V) (Power circuit) 800 800 800 800 800 800
Rated impulse withstand voltage Uimp (kV) (power circuit) 6 6 6 6 6 6
Rated insulation voltage Ui (V) (control circuit) 300 300 300 300 300 300
Rated impulse withstand voltage Uimp (kV) (control circuit) 4 4 4 4 4 4
Rated operational currents
(A)
IEC 60947-3 at 415 VAC
at 40°C
AC 21A / 21 B 40/40 63/63 80/80 100/100 125/125 160/160
AC 22A / 22 B 40/40 63/63 80/80 100/100 125/125 125/160
AC 23A / 23 B 40/40 63/63 80/80 100/100 125/125 125/160
Rated operational currents
(A) IEC 60947-6-1 415Vac
at 40°C
AC 33B / AC32B
**AC 33iB
40/40 63/63 80/80 100/100 125/125 125**/160
Fuse protected short-
circuit withstand if using
gG DIN fuses
Fuse protected short-circuit
withstand (kA eff)
50 50 50 50 50 40
Associated fuses (gG DIN) 40 63 80 100 125 160
Short-circuit capacity
Rated short-term withstand current:
Icw 1s (kA eff)
4 4 4 4 4 4
Rated short-term withstand current:
Icw 30ms (kA eff)
10 10 10 10 10 10
Switching time at In
excluding loss of supply
sensing time and
excluding any delay timers
applicable.
I-II or II-I (ms) 180 180 180 180 180 180
Duration of “electrical blackout” at
Un (ms)
90 90 90 90 90 90
I-O / O-I / II-O / O-II (ms) 45 45 45 45 45 45
Consumption
Inrush current(A) 20 20 20 20 20 20
Consumption in stabilised state (VA) 6 6 6 6 6 6
Mechanical characteristics Number of changeovers 10000 10000 10000 10000 10000 10000
Connection cross-section
(
not compatible with
aluminium cables)
Minimum size (Cu mm²), flexible and
rigid
10 10 10 10 10 10
Maximum size (Cu mm²), flexible
and rigid
70 70 70 70 70 70
Equipment class (According to IEC 60947-6-1) PC PC PC PC PC PC
EMC environment A A A A A A
* Possibility of reaching 125A with bigger connection cross-sections and use of the 160A bridging bar.
** AC 33iB 160A according to GB 14048.11.
This is a class A product. In a domestic environment, this product may cause radio interference in which
case the user may be required to take adequate measures.

socomec ATyS Series Specifications

General

Type	Automatic Transfer Switch (ATS)
Transfer Mode	Open or closed transition
Control	Automatic, Manual, Remote
Standards	IEC 60947-6-1
Communication	Modbus, Ethernet
Protection Degree	IP20
Poles	3 or 4 poles
