socomec ATyS Series Installation And Operating Manual

ATyStM - 542931D - SOCOMEC
17EN
9.3. Bridging bars 4P
Ratings ≤ 125A: ref. 1309 4006; 160A : ref.1309 4016
10 to
70 mm²
15mm
Hexagonal Metric
Allen size 4
5,0 Nm
RJRS
207208 209210 43 44 5354 63 64 73 74
2 4 6
8
1
3
5 7
2 4 6
8
1
3
5 7
2 4 6 8
1 3 5 7
2 4 6 8
1 3 5 7
/
RJRS
207208 209210 43 44 5354 63 64 73 74
/
2 4 6
8
1
3
5 7
2 4 6
8
1
3
5 7
2 4 6 8
1 3 5 7
2 4 6 8
1 3 5 7
LOAD
LOAD
Source I
Source I
Source II
Source II
Allen size 4
Hexagonal Metric
44,1 lb-in 5,0 Nm
15 mm / 0,59 "
# 8 to # 00 AWG
10 to 70 mm
2
6 to 70 mm
2
*
# 10 to # 00 AWG
!
X8
Allen size 4
Hexagonal Metric
44,1 lb-in 5,0 Nm
15 mm / 0,59 "
# 8 to # 00 AWG
10 to 70 mm
2
6 to 70 mm
2
*
# 10 to # 00 AWG
!
X8
Bridging bar.
125A: 1309 4006
160A: 1309 4016
OK NOK
Make sure that the bridging bar is tted to the correct set of terminals.
There are two references available: one for ratings up to 125A, and another for 160A rating.
9.4. Terminal shrouds
Ref. 22944016
°C
°K
°C
°K
9.5. Sealable cover
Ref. 1359 0000

socomec ATyS Series Specifications

General

Type	Automatic Transfer Switch (ATS)
Transfer Mode	Open or closed transition
Control	Automatic, Manual, Remote
Standards	IEC 60947-6-1
Communication	Modbus, Ethernet
Protection Degree	IP20
Poles	3 or 4 poles
