ATyStM - 542931D - SOCOMEC
23EN
12.2. Auxiliary contact operating schedule
Position I
Position 0
Position II
C.A. Position I
C.A. Position 0
C.A. Position II
11-14 Closed
11-12 Open
01-04 Closed
01-02 Open
21-24 Closed
21-22 Open
Position I
Position 0
Position II
C.A. Position I
C.A. Position 0
C.A. Position II
