HYD 5/6/8/10/15/20KTL-3PH USER MANUAL
76
otherwise “Not Use”
PV Channel2
if PV strings are connected to PV2
independently, select “PV Input 2”
If PV strings are connected to PV2 in
parallel to PV1, select “PV Input 1”,
otherwise “Not Use”
5) Set battery
parameters
Default values can be set according
to the input channel configuration
in Menu Advanced Settings – Battery
Parameter:
Select Battery Type
Max. charging current (25A)
Max. discharging current (25A)
Discharge Depth（80%）
The default operating mode is the Self-use Mode.
EPS Mode, Unbalanced Support, Feed-in Limitat, IV-Curve Scan
and Logic interface are disabled.
6.4.1 Configuring the battery setup
The HYD 5/6/8KTL-3PH models have one battery input (max.
current 25 A). The HYD 10/15/20KTL-3PH models have two
battery inputs (max. current 25 A / 25 A).
Battery inputs can be connected and set in parallel mode to
reach 50 A / 70 A.
6.4.2 Configuring Parallel Inverter System
To increase the system's EPS and grid power, the HYD
5/6/8/10/15/20KTL-3PH can be parallelly connected at the Grid
port and the EPS port.
For the communication setup, please follow the following steps:
1) Set the Master unit
2) Set the Slave units
NOTE
 Each inverter must have a unique parallel address
