11 • Technical Data
________________________________________________________________________________________________
3.9 Synchronized mode
This mode of operation is applicable only if mode of operation is set to ZERO CROSSING.
In this mode of operation the TPS Sync. Terminals should be wired in “daisy chain” as shown in section
4.4 on
page14. This mode is used to time share the ON time (Ton) period between the units.
In this mode, the beginning of the ON cycles of the connected TPSs is equally shifted.
For example:
No. of TPS units – 3
Cycle time when TPS is in ZERO CROSSING (Tct – see section
3.8.1 page 9) – 3 seconds.
In this example TPS#1 will be set to master and TPS#2, TPS#3 will be set to slave.
When system is stated, TPS#1 will go to ON first, TPS#2 will go to ON after 1 second (3 seconds/3), TPS#3
will go to ON after 2 seconds.
So, if the required duty cycle (Ton/Tct) is less than 1/3, one TPS only can be in ON state.
The Master is transmitting a “Sync” signal, received by all connected TPSs (Sync group members).
Only one unit of the group should be set as Master. All others should be set as slaves.
Refer to section
7.7.4 page 34 for programming.
Notes:
1. Sync. LED will lit once function is enabled.
2. In order to have a full number of ON cycles it is recommended to program the ON-OFF CYCLE
time In such manner that the number of cycles (50 or 60 Hz) divided by the number of connected TPS
units will be an integer . i.e. if 3 TPS units are connected with 50Hz mains, the ON-OFF time can be,
for example, 0.9Sec (45 cycles), 1,2 Sec (60 cycles), 3Sec (150 cycles).
3. Synchronized mode cannot be implemented if one current analog input is connected to several TPS
units in series.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Solcon TPS and is the answer not in the manual?

Solcon TPS Specifications

General Specifications IconGeneral Specifications
rated current8-1500A
rated voltage120 - 1000VAC +10% -15%
control voltage120 or 230VAC, 110VDC+10% -15%
frequency50 / 60 Hz
controlled phasesThree
short-circuit current25kA
rated insulation voltage690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand6kV (Mains), 2.5kV (control)
degree of protectionIP00
pollution degree3
ambient temperature operating-10 – + 50°C
ambient temperature storage-20 – + 70°C
altitudeTo 1000 m ASL W/O de-rating
coolingForced air (fans)
number of CTsThree
connection modesWye - Neutral connected / not connected
Control Specifications IconControl Specifications
control methodDigital
firing methodZero crossing, Phase control, Phase control-power
on-off time cycle1000 – 10000 mSec.
analog input0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputsStart/Stop (with internal 0-60 sec time delays), Aux. contact
output relays3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC2000 VA
max. DC load breaking capacity8A at 30VDC.
synchronizationOne master and 2-9 connected slaves
Fan and TPS Consumption Ratings IconFan and TPS Consumption Ratings
TPS 8-31A consumption21W
TPS 44-72A consumption36W
TPS 85-105A consumption26W
TPS 145-170A consumption35W
TPS 210-460A consumption64W
TPS 580-820A consumption100W
TPS 55-200A 1000V consumption40W
