3.5 Mains and control description
Indication Description Remarks
L1, L2, L3 Connection to mains voltage up to 690V.
Three Main Voltage levels are available:
400V (230-400V), 480V, 600V,690V and
1000V.
Note:
400V applies for 230 to 400V.
U, V, W Connection to resistive/inductive load. Load connection must be programmed to
TPS. Refer to section
3.7 page 9.
G Connection to Ground.
Terminal 1 Control phase (Positive – for DC control)
Three control voltages are available:
115VAC (50/60Hz), 230VAC (50/60Hz),
110VDC.
Terminal 3 Control Neutral (Return)
Terminal 4 Input – RUN command.
Terminal 5 Input - Auxiliary programmable input. Auxiliary Input can be programmed as one
of the options:
SYNC.
AUTHORIZED KEY
REMOTE RESET
N.C. EXT. FAULT
N.O. EXT. FAULT
N.C. INTERLOCK
N.O. INTERLOCK
Refer to section
7.7.2 page 30.
Terminal 6 Common. This terminal is a reference to terminals 4
& 5.
Terminal 7 Programmable output relay A –
Common.
Any of the output relays A, B or C can be
programmed to one of the following
functions:
Run, Alarm, Alarm fail safe, Trip, Trip fail
safe, Tripping/Alarm (Any fault
programmed in the tripping and alarm
options will energize the relay.)
Refer to section
7.7.2 page 30 for
programming output relays.
Terminal 8 Programmable output relay A –
Normally open (NO).
Terminal 9 Programmable output relay A –
Normally closed (NC).
Terminal 10 Programmable output relay B –
Common.
Terminal 11 Programmable output relay B –
Normally open (NO).
Terminal 12 Programmable output relay B –
Normally closed (NC).
Terminal 13 Programmable output relay C –
Common.
Terminal 14 Programmable output relay C –
Normally open (NO).
Terminal 15 Programmable output relay C –
Normally closed (NC).
