Solcon TPS User Manual

5 • Technical Data
________________________________________________________________________________________________
3. TECHNICAL DATA
3.1 Introduction
Solcons’ Thyristor based Power System (TPS) is a heavy duty fully digital, Zero-crossing, Phase Control or
Phase Control-Power, three phase control power unit for all types of Resistive/Inductive loads (temperature
control of heaters, etc.).
Providing a wide range 8-1500A, 230-1000V, 50/60Hz, it can be installed in a variety of heating systems.
Control of output voltage can be done by input signal of 0-10VDC, 4-20mA, 0-20mA, by a potentiometer
(Optional) or via communication (Optional) for precision temperature control.
A special optional digital synchronization system enables load sharing and prevents excessive loading in multi
controller applications.
Fully programmable with 9 protection functions, including “Load Unbalance” alarm to detect a faulty element,
even in parallel connected element system and “Under power level” alarm to detect faulty element in case the
system is designed to work unbalanced.
Two line, 16 character LCD display is used for the TPS programming, actual values, statistical & maintenance
data.
Options:
- Potentiometer input for control. (Without the need for external power supply)
- Multi TPS synchronization system for load shedding
- RS-485 communication for TPS programming, remote data readings and controlling.
- Analogue output PCB (4-20mA, 0-20mA or 0-10V).
3.2 Rating, Frames sizes and Weights
Please note that the company reserves the right to
make any improvements or modifications to its
products without prior notice!
Refer to section
5 page 15 for detailed
dimensional drawings
3.3 TPS Selection
Select the TPS according to LOAD RATED CURRENT(FLA) - as indicated on its nameplate.
Note:
TPS withdrawn current by the load must not exceed TPS RATED CURRENT in each and every phase of the
TPS!
TPS
type
up to
690VAC
Rated
Current
[A]
Dimensions
WxHxD
[mm]
Weight
[Kg]
TPS 8 8 172x291x185 6.3
TPS 17 17 172x291x185 6.3
TPS 31 31 172x291x185 6.4
TPS 44 44 172x291x185 6.5
TPS 58 58 172x291x185 6.5
TPS 72 72 172x291x185 6.5
TPS 85 85 172x390x195 8.5
TPS 105 105 172x390x195 8.5
TPS 145 145 274x385x238 14.5
TPS 170 170 274x385x238 14.5
TPS 210 210 274x385x238 14.5
TPS 310 310 380x455x292 31
TPS 390 390 380x455x292 31
TPS 460 460 380x555x292 51
TPS 580 580 470x640x302 53
TPS 820 820 470x640x302 53
TPS 950 950 Consult factory
TPS 1100 1100 Consult factory
TPS 1500 1500 Consult factory
TPS
Model
1000VAC
Rated
Current
[A]
Dimensions
WxHxD
[mm]
Weight
[Kg]
TPS 55 55 280x550x346 33.5
TPS 105 105 280x550x346 33.5
TPS 160 160 280x550x346 33.5
TPS 200 200 280x550x346 33.5

Solcon TPS Specifications

General Specifications

rated current	8-1500A
rated voltage	120 - 1000VAC +10% -15%
control voltage	120 or 230VAC, 110VDC+10% -15%
frequency	50 / 60 Hz
controlled phases	Three
short-circuit current	25kA
rated insulation voltage	690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand	6kV (Mains), 2.5kV (control)
degree of protection	IP00
pollution degree	3
ambient temperature operating	-10 – + 50°C
ambient temperature storage	-20 – + 70°C
altitude	To 1000 m ASL W/O de-rating
cooling	Forced air (fans)
number of CTs	Three
connection modes	Wye - Neutral connected / not connected

Control Specifications

control method	Digital
firing method	Zero crossing, Phase control, Phase control-power
on-off time cycle	1000 – 10000 mSec.
analog input	0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputs	Start/Stop (with internal 0-60 sec time delays), Aux. contact
output relays	3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC	2000 VA
max. DC load breaking capacity	8A at 30VDC.
synchronization	One master and 2-9 connected slaves

Fan and TPS Consumption Ratings

TPS 8-31A consumption	21W
TPS 44-72A consumption	36W
TPS 85-105A consumption	26W
TPS 145-170A consumption	35W
TPS 210-460A consumption	64W
TPS 580-820A consumption	100W
TPS 55-200A 1000V consumption	40W
