Solcon TPS User Manual

30 • Control Keypad
________________________________________________________________________________________________
7.7.2 I/O Parameters – page 2
I/O PARAMETERS
SETTINGS
Display and default
values
Range Description
ANALOG IN TYPE
4 .. 20 mA
0 .. 10 V
0 ..20 mA
4 .. 20 mA
Sets TPS type of input control input. (Terminals 16-
17)
0 . . 10V is programmed when analogue input is 0 ..
10V or potentiometer option is installed.
0 . . 20mA is programmed when analogue input is 0 ..
20mA.
4 . . 20mA is programmed when analogue input is 4 ..
20mA.
Notes:
1. Customer must set jumpers settings to set TPS
hardware for programmed ANALOG IN TYPE.
Refer to section
6.4 on page 20.
2. When using potentiometer option program
ANALOG IN TYPE to 0 .. 10V.
3. Synchronized mode cannot be implemented if one
current analog input is connected to several TPS
units in series.
ANALOG IN T. CONST
1.0 SEC.
0.0 SEC. – 10.0 SEC. Sets TPS time constant.
When starting the TPS, even if analogue input is high,
the ANALOG IN T. CONST function will gradually
increase the “internal” value of the analogue input
while TPS will function in PHASE CONTROL mode.
.
AUX. IN TYPE
REMOTE RESET
SYNC.
AUTHORIZED KEY
REMOTE RESET
N.C. EXT. FAULT
N.O. EXT. FAULT
N.C. INTERLOCK
N.O. INTERLOCK
Sets TPS AUX IN TYPE. (Terminal 5).
SYNC. Is for future enhancement.
AUTHORIZED KEY is programmed to prevent
parameter modifications.
N.O./N.C. EXT. FAULT is programmed when
auxiliary fault signal is initiated to the TPS.
N.C./N.O. INTERLOCK is programmed to interlock
the TPS with auxiliary signals.
CONFIG OUT A
RUN (IMMEDIATE)
KWH PULSE RELAY
TRIPPING/ALARM
TRIP-FAIL SAFE
TRIP
ALARM-FAIL SAFE
ALARM
RUN (IMMEDIATE)
Sets TPS functions of output relay A (Terminals 7, 8,
9)
KWH PULSE RELAY is programmed when output
pulse is needed for KWH metering. The rated
KWH/pulse is programmed in KWH PER PULSE
parameter. (See here after)
TRIPPING/ALARM is programmed when this OUT
RELAY is programmed as TRIPPING/ALARM.
TRIP-FAIL SAFE is programmed when this OUT
RELAY is programmed as TRIP-FAIL SAFE.
TRIP is programmed when this OUT RELAY is
programmed as TRIP.
ALARM-FAIL SAFE is programmed when this OUT
RELAY is programmed as ALARM-FAIL SAFE.
ALARM is programmed when this OUT RELAY is
programmed as ALARM.
RUN (IMMEDIATE) is programmed when this OUT
RELAY is programmed as RUN (IMMEDIATE) and
closes when TPS is in RUN mode.
OUT A RELAY DLY
0.0 SEC.
0.0 SEC.-60.0 SEC. Sets delay time for this OUT RELAY.

Solcon TPS Specifications

General Specifications

rated current	8-1500A
rated voltage	120 - 1000VAC +10% -15%
control voltage	120 or 230VAC, 110VDC+10% -15%
frequency	50 / 60 Hz
controlled phases	Three
short-circuit current	25kA
rated insulation voltage	690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand	6kV (Mains), 2.5kV (control)
degree of protection	IP00
pollution degree	3
ambient temperature operating	-10 – + 50°C
ambient temperature storage	-20 – + 70°C
altitude	To 1000 m ASL W/O de-rating
cooling	Forced air (fans)
number of CTs	Three
connection modes	Wye - Neutral connected / not connected

Control Specifications

control method	Digital
firing method	Zero crossing, Phase control, Phase control-power
on-off time cycle	1000 – 10000 mSec.
analog input	0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputs	Start/Stop (with internal 0-60 sec time delays), Aux. contact
output relays	3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC	2000 VA
max. DC load breaking capacity	8A at 30VDC.
synchronization	One master and 2-9 connected slaves

Fan and TPS Consumption Ratings

TPS 8-31A consumption	21W
TPS 44-72A consumption	36W
TPS 85-105A consumption	26W
TPS 145-170A consumption	35W
TPS 210-460A consumption	64W
TPS 580-820A consumption	100W
TPS 55-200A 1000V consumption	40W
