39 • TROUBLE SHOOTING
________________________________________________________________________________________________
8. TROUBLE SHOOTING
Upon fault – load stops, Fault LED lights and Fault Relay operates (as programmed). The LCD shows TRIP:
and fault description. (for example: TRIP: UNDER CURRENT).
Fault Massage Cause and trouble shooting
UNDER CURRENT Trips/Alarms if UNDER CURRENT conditions exist.
For more information on adjusting UNDER CURRENT refer to section
7.7.5 on page 32
OVER CURRENT Trips/Alarms if TPS if UNDER CURRENT conditions exist.
For more information on adjusting OVER CURRENT refer to section
7.7.5
on page 32
UNBALANCE LVL 1,
UNBALANCE LVL 2
Trips/Alarms if UNBLANCE LEVELS exist.
This alarm can be used when symmetrical load is connected to alert faulty
elements.
In case of an a-symmetrical load disable this protection.
Check load for faulty elements.
For more information on adjusting UNBALANCE LVLs refer to section
7.7.5
on page 32
UNDER VOLTAGE,
OVER VOLTAGE
Trips/Alarms if UNDER/OVER VOLTAGE conditions exist.
For more information on adjusting UNDER/OVER VOLTAGE levels refer
to section
7.7.5 on page 32
PHASE LOSS Trips/Alarms when one phase is missing.
When two/three phases are missing the UNDER VOLTAGE alarm will
show.
Check connections to TPS.
GROUND FAULT Trips/Alarms when line currents measured are not summed to zero.
This alarm does not function when using WYE NEUTRAL CONNECTED.
Check load for ground fault.
Note: This alarm is very sensitive.
Disable this protection in case of consecutive nuisance alarms.
UNDER POWER Trips/Alarms when power derived from mains is lower then power
programmed to TPS.
This alarm can be used when an a-symmetrical load is connected to alert
faulty elements.
Check load for faulty elements.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Solcon TPS and is the answer not in the manual?

Solcon TPS Specifications

General Specifications IconGeneral Specifications
rated current8-1500A
rated voltage120 - 1000VAC +10% -15%
control voltage120 or 230VAC, 110VDC+10% -15%
frequency50 / 60 Hz
controlled phasesThree
short-circuit current25kA
rated insulation voltage690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand6kV (Mains), 2.5kV (control)
degree of protectionIP00
pollution degree3
ambient temperature operating-10 – + 50°C
ambient temperature storage-20 – + 70°C
altitudeTo 1000 m ASL W/O de-rating
coolingForced air (fans)
number of CTsThree
connection modesWye - Neutral connected / not connected
Control Specifications IconControl Specifications
control methodDigital
firing methodZero crossing, Phase control, Phase control-power
on-off time cycle1000 – 10000 mSec.
analog input0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputsStart/Stop (with internal 0-60 sec time delays), Aux. contact
output relays3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC2000 VA
max. DC load breaking capacity8A at 30VDC.
synchronizationOne master and 2-9 connected slaves
Fan and TPS Consumption Ratings IconFan and TPS Consumption Ratings
TPS 8-31A consumption21W
TPS 44-72A consumption36W
TPS 85-105A consumption26W
TPS 145-170A consumption35W
TPS 210-460A consumption64W
TPS 580-820A consumption100W
TPS 55-200A 1000V consumption40W
