37 • Control Keypad
________________________________________________________________________________________________
7.7.7 Actual data – page 7
ACTUAL DATA
--****--
Display Description
Vp1 Vp2 Vp3
0 0 0 V
Displays system phase voltage.
If no neutral in the system, a “virtual ground” is used for measuring phase
voltage.
VL12 VL23 VL31
0 0 0 V
Displays system line voltage.
ANALOG INPUT
26%
Displays ANALOG INPUT rate.
ON I1 I2 I3
0 0 0 A
Displays currents of 3 phases. The current shown is when TPS is in “ON” during
the “ON-OFF CYCLE T” in “ZERO CROSSING” MODE.
This display (with “ON” shown on top left of the display) shown in “ZERO
CROSSING” mode. In “PHASE CONTROL” mode the “ON” is not shown on the
display.
GROUND CURRENT
0 AMP.
Display calculated GROUND CURRENT.
Notes:
Not active when WYE NEUTRAL CON is programmed.
When TPS is in ZERO CROSSING mode of operation, the calculated current
used for this function is the ON state current value.
FREQUENCY
50 Hz
Display measured system frequency.
POWER
0 KW
Display measured system power.
LOAD CURRENT
0 % OF FLA
Display measured current as a ratio of LOAD RATED CURRENT (FLA).
UNBALANCE CURR.
0 %
Display unbalance current as a ratio of .
To Next Page
