7.7 Mode Pages, parameters & default values
MAIN PARAMETERS
SETTINGS
I/O PARAMETERS
SETTINGS
PROTECTION PARA.
SETTINGS
LOAD SHED. PARA.
SETTINGS
TRIPPING/ALARM
***OPTIONS***
See page 28 See page 30 See page 32 See page 34 See page 35
Display and default values Display and default values Display and default
values
Display and default
values
LINE VOLTS (Vn)
400V
ANALOG IN TYPE
4 .. 20mA
UNDER CURRENT
0 % OF FLA
CURRENT LIMIT
OFF
LINE FREQUENCY
50 Hz
ANALOG IN T. CONST 1.0
SEC.
U/C DELAY
10.0 SEC.
MASTER/SLAVE
OFF
TPS RATED CURR.
100 AMP.
AUX. IN TYPE
REMOTE RESET
OVER CURRENT
120 % OF FLA
NO. OF SYNC UNITS
5
LOAD RATED CURR.
100 AMP.
CONFIG OUT A
RUN (IMMEDIATE)
O/C DELAY
5.0 SEC.
SYNC. NUMBER
2
LOAD RATED POWER
69.3 KW
OUT A RELAY DLY
0.0 SEC.
UNBALANCE LVL 1
10% OF FLA
STORE ENABLE
LOAD SHED. PARA.
CONNECTION TYPE
WYE, NEUTRAL CON
CONFIG OUT B
ALARM-FAIL SAFE
U/B LVL 1 DELAY
10.0 SEC.
LOAD POWER FACTOR
1.0
OUT B RELAY DLY
0.0 SEC.
UNBALANCE LVL 2
20% OF FLA
FIRING METHOD
ZERO CROSSING
CONFIG OUT C
TRIP
U/B LVL 2 DELAY
5.0 SEC.
CONTROL MODE
INPUT SIGNAL
OUT C RELAY DLY
0.0 SEC.
UNDER VOLTAGE
80 % OF Vn
ON-OFF CYCLE T
2.0 SEC.
KWH PER PULSE
OFF
U/V DELAY
5.0 SEC.
TURN ON DELAY
0.0 SEC.
AN. OUT PARAMETER
P, 0-100% OF Pn
OVER VOLTAGE
115 % OF Vn
TURN OFF DELAY
0.0 SEC.
STORE ENABLE
I/O PARAMETERS
O/V DELAY
1.0 SEC.
PARAM. SETTING
NOT LOCKED
PHASE LOSS DELAY
2.0 SEC.
STORE ENABLE
MAIN PARAMETERS
GND FAULT LEVEL
10 % OF FLA
GND FAULT DELAY
2.0 SEC.
UNDER POWER LVL
0 % OF Pn
UNDER POWER DLY
10.0 SEC.
EXT. FAULT DELAY
5.0 SEC.
STORE ENABLE
PROTECTION PARA.

Solcon TPS Specifications

General Specifications

rated current	8-1500A
rated voltage	120 - 1000VAC +10% -15%
control voltage	120 or 230VAC, 110VDC+10% -15%
frequency	50 / 60 Hz
controlled phases	Three
short-circuit current	25kA
rated insulation voltage	690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand	6kV (Mains), 2.5kV (control)
degree of protection	IP00
pollution degree	3
ambient temperature operating	-10 – + 50°C
ambient temperature storage	-20 – + 70°C
altitude	To 1000 m ASL W/O de-rating
cooling	Forced air (fans)
number of CTs	Three
connection modes	Wye - Neutral connected / not connected

Control Specifications

control method	Digital
firing method	Zero crossing, Phase control, Phase control-power
on-off time cycle	1000 – 10000 mSec.
analog input	0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputs	Start/Stop (with internal 0-60 sec time delays), Aux. contact
output relays	3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC	2000 VA
max. DC load breaking capacity	8A at 30VDC.
synchronization	One master and 2-9 connected slaves

Fan and TPS Consumption Ratings

TPS 8-31A consumption	21W
TPS 44-72A consumption	36W
TPS 85-105A consumption	26W
TPS 145-170A consumption	35W
TPS 210-460A consumption	64W
TPS 580-820A consumption	100W
TPS 55-200A 1000V consumption	40W
