Solcon TPS User Manual

27 • Control Keypad
________________________________________________________________________________________________
COMM.PARAMETERS
SETTINGS
ACTUAL DATA
--****--
STATISTICAL DATA
- **** -
FAULT DATA
- **** -
See page 36 See page 37 See page 38 See page 38
Display and default
values
Display Display Display
COMM. PROTOCOL
MODBUS
Vp1 Vp2 Vp3
0 0 0 V
TOTAL RUN TIME
0 HOURS
LAST TRIP
NO DATA
BAUD RATE
19200
VL12 VL23 VL31
0 0 0 V
TOTAL # OF TRIPS
0
LAST ALARM
NO DATA
PARITY CHECK
EVEN
ANALOG INPUT
26%
TOTAL ENERGY
0 KWH
TRIP I1 I2 I3
0 0 0 A
SERIAL LINK NO.
248 (OFF)
ON I1 I2 I3
0 0 0 A
TRIP GND CURRENT
0 AMP.
S.LINK PAR. SAVE
DISABLE
GROUND CURRENT
0 AMP.
TRIP Vp1 Vp2 Vp3
0 0 0 V
SER.LINK CONTROL
DISABLE
FREQUENCY
50 Hz
LAST 10 TRIPS:
NO DATA
STORE ENABLE
COMM. PARAMETERS
POWER
0 KW
PREVIOUS TRIP -2
NO DATA
.
LOAD CURRENT
0 % OF FLA
.
PREVIOUS TRIP -9
NO DATA
UNBALANCE CURR.
0 %

Solcon TPS Specifications

General Specifications

rated current	8-1500A
rated voltage	120 - 1000VAC +10% -15%
control voltage	120 or 230VAC, 110VDC+10% -15%
frequency	50 / 60 Hz
controlled phases	Three
short-circuit current	25kA
rated insulation voltage	690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand	6kV (Mains), 2.5kV (control)
degree of protection	IP00
pollution degree	3
ambient temperature operating	-10 – + 50°C
ambient temperature storage	-20 – + 70°C
altitude	To 1000 m ASL W/O de-rating
cooling	Forced air (fans)
number of CTs	Three
connection modes	Wye - Neutral connected / not connected

Control Specifications

control method	Digital
firing method	Zero crossing, Phase control, Phase control-power
on-off time cycle	1000 – 10000 mSec.
analog input	0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputs	Start/Stop (with internal 0-60 sec time delays), Aux. contact
output relays	3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC	2000 VA
max. DC load breaking capacity	8A at 30VDC.
synchronization	One master and 2-9 connected slaves

Fan and TPS Consumption Ratings

TPS 8-31A consumption	21W
TPS 44-72A consumption	36W
TPS 85-105A consumption	26W
TPS 145-170A consumption	35W
TPS 210-460A consumption	64W
TPS 580-820A consumption	100W
TPS 55-200A 1000V consumption	40W
