Solcon TPS User Manual

6 • Technical Data
________________________________________________________________________________________________
3.4 Ordering Information
TPS 31- 400- 230- 230- 0- S
Full load
Current
Mains
Voltage
Control
Voltage
Control
inputs
Voltage
Options Front Panel
Full load Current
Specify Description
TPS - Rated Current [A]
Models 400-690VAC
8, 17, 31, 44, 58, 72, 85, 105, 145, 170, 210, 310, 390, 460, 580, 820, 950, 1100,
1500
TPS - Rated Current [A]
Models 1000VAC
55, 105, 160, 200
Mains Voltage
Specify Description
400 230 – 400 VAC, +10% -15%, 50/60Hz
480 480 VAC, +10% -15%, 50/60Hz
600 600 VAC, +10% -15%, 50/60Hz
690 690 VAC, +10% -15%, 50/60Hz
1000 1000 VAC, +10% -15%, 50/60Hz
Control Voltage
Specify Description
115 115 VAC, 50/60Hz, +10% -15%
230 230 VAC, 50/60Hz, +10% -15%
110 VDC 110 VDC
(1)
, +10% -15%
24VDC 24 VDC
(1)
Notes:

(1)
For DC control voltage or control inputs voltage - consult factory.
Options
Specify Description
0 No options
3M Communication RS-485 (MODBUS)
(1)
5 Analogue card
(1)
8 Harsh environment treatment
(1)
D Remote panel mounting replacing the original panel. (Supplied with 1.5 m cable).
(1)
,
(2)
Sync. Synchronization between up to 10 TPS units.
(1)
P Potentiometer control. (No need for external power source)
(1)
RU Russian display
Notes: For more than one option indicate, for example: 8+5 (Harsh environment and analogue
card)
(1)
Must be ordered in factory – cannot be installed on site.
(2)
D option is available for TPS 145A and up.
Front Panel
Specify Description
S Standard
Example:
TPS rated 820A, mains voltage - 230V, control voltage- 230VAC, control inputs- 48VDC Modbus
communication card, Harsh environment treatment, Synchronized TPS and standard front panel: TPS 820 -
230 – 230 - 48 - 3M+8+SYNC – S
Control inputs voltage
Specify Description
115 or 230 90 – 230 VAC, 50/60Hz or 90 – 230 VDC
24 24VAC, 50/60Hz or 24VDC
(1)
48 48VAC, 50/60Hz or 48VDC
(1)
Notes:

(1)
For DC control voltage or control inputs voltage - consult factory.

Solcon TPS Specifications

General Specifications

rated current	8-1500A
rated voltage	120 - 1000VAC +10% -15%
control voltage	120 or 230VAC, 110VDC+10% -15%
frequency	50 / 60 Hz
controlled phases	Three
short-circuit current	25kA
rated insulation voltage	690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand	6kV (Mains), 2.5kV (control)
degree of protection	IP00
pollution degree	3
ambient temperature operating	-10 – + 50°C
ambient temperature storage	-20 – + 70°C
altitude	To 1000 m ASL W/O de-rating
cooling	Forced air (fans)
number of CTs	Three
connection modes	Wye - Neutral connected / not connected

Control Specifications

control method	Digital
firing method	Zero crossing, Phase control, Phase control-power
on-off time cycle	1000 – 10000 mSec.
analog input	0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputs	Start/Stop (with internal 0-60 sec time delays), Aux. contact
output relays	3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC	2000 VA
max. DC load breaking capacity	8A at 30VDC.
synchronization	One master and 2-9 connected slaves

Fan and TPS Consumption Ratings

TPS 8-31A consumption	21W
TPS 44-72A consumption	36W
TPS 85-105A consumption	26W
TPS 145-170A consumption	35W
TPS 210-460A consumption	64W
TPS 580-820A consumption	100W
TPS 55-200A 1000V consumption	40W
