Solcon TPS User Manual

38 • Control Keypad
________________________________________________________________________________________________
7.7.8 Statistical data – page 8
STATISTICAL DATA
- **** -
Display and default
values
Description
TOTAL RUN TIME
0 HOURS
Displays TOTAL RUN TIME of the TPS since last statistics reset..
TOTAL # OF TRIPS
0
Displays TOTAL # OF TRIPS since last statistics reset.
TOTAL ENERGY
0 KWH
Displays TOTAL ENERGY drawn by the TPS in KWH since last statistics reset.
7.7.9 Fault data – page 9
FAULT DATA
- **** -
Display and default
values
Description
LAST TRIP
NO DATA
Displays TPS LAST TRIP cause.
LAST ALARM
NO DATA
Displays TPS LAST ALARM cause.
TRIP I1 I2 I3
0 0 0 A
Displays TPS I1, I2, I3 when LAST TRIP occurred.
TRIP GND CURRENT
0 AMP.
Displays TPS calculated GND CURRENT when LAST TRIP occurred.
TRIP Vp1 Vp2 Vp3
0 0 0 V
Displays TPS MEASURED PHASE VOLTAGE when LAST TRIP occurred.
LAST 10 TRIPS:
NO DATA
Displays TPS last trips.
PREVIOUS TRIP -2
NO DATA
.
.
.
.
.
.
.
.
.
PREVIOUS TRIP -9
NO DATA

Solcon TPS Specifications

General Specifications

rated current	8-1500A
rated voltage	120 - 1000VAC +10% -15%
control voltage	120 or 230VAC, 110VDC+10% -15%
frequency	50 / 60 Hz
controlled phases	Three
short-circuit current	25kA
rated insulation voltage	690V (120-690V mains models), 1000V (1000V mains models), 250V (control circuits)
rated impulse withstand	6kV (Mains), 2.5kV (control)
degree of protection	IP00
pollution degree	3
ambient temperature operating	-10 – + 50°C
ambient temperature storage	-20 – + 70°C
altitude	To 1000 m ASL W/O de-rating
cooling	Forced air (fans)
number of CTs	Three
connection modes	Wye - Neutral connected / not connected

Control Specifications

control method	Digital
firing method	Zero crossing, Phase control, Phase control-power
on-off time cycle	1000 – 10000 mSec.
analog input	0-10V >100KΩ / 4-20 mA, 0-20mA <100Ω
control inputs	Start/Stop (with internal 0-60 sec time delays), Aux. contact
output relays	3 programmable (1-C/O) (8A/250VAC)
maximum breaking capacity AC	2000 VA
max. DC load breaking capacity	8A at 30VDC.
synchronization	One master and 2-9 connected slaves

Fan and TPS Consumption Ratings

TPS 8-31A consumption	21W
TPS 44-72A consumption	36W
TPS 85-105A consumption	26W
TPS 145-170A consumption	35W
TPS 210-460A consumption	64W
TPS 580-820A consumption	100W
TPS 55-200A 1000V consumption	40W
