Solid State Logic Nucleus2 User Manual

Nucleus
2
User Guide Page 17
Direct Network Connection Configuration (Mac)
Connect your Nucleus
2
directly to the DAW computer using a standard network cable, and check that the IP address is set
to Fixed in the Nucleus
2
Remote (see previous page).
OS X does not currently allow two ports to be used for IP traffic – your main network connection will become
unavailable when using Nucleus
2
.
• On the Mac, open the Network control panel in System
Preferences and use the LOCATION: drop-down to create
a new location. Next, select the Mac Ethernet port to
which you have connected Nucleus
2
and configure ipv4
to Using DHCP (as shown). The computer will ‘fall over’
to a static IP address in the link local range.
On OSX version 10.11 ‘El Capitan’, a router address will be
required for two-way data communications. For this
reason you will need to manually enter a static IP address
with a ‘Router’ address. Set Configure ipv4: to Manually,
IP Address: to 169.254.1.1, Subnet Mask: to 255.255.0.0,
and Router: address to the IP address of the console,
typically 169.254.1.2.
• Launch the Nucleus
2
Remote application and check it
connects to your Nucleus
2
, as described on Page 21.
Wider Network with a DHCP Server Configuration (Mac)
For connecting Nucleus
2
to a wider network (a multi-studio facility for example), you will need to set the Mac Network
setting ‘Configure IPV4’ to Using DHCP. The same must be done in the Nucleus Remote ‘Network’ Tab.
Both the Nucleus
2
and your computer will then be assigned IP addresses automatically.
If using more than one ipMIDI controller/console, a pre-configured switch is available from the SSL web store which
will prevent the two consoles from communicating across the network.
Direct Network Connection Configuration (Windows)
• Connect your Nucleus
2
directly to the DAW computer using a standard
network cable, and then check that the IP address is set to Fixed in the
Nucleus
2
Remote (see Page 14)
• On the PC, open the control panel, click on ‘view network status and
tasks’, the ‘local area connection’ for your Nucleus
2
, ‘Properties’, then
double-click ‘Internet Protocol Version 4 (TCP/IPV4). Make sure that the
port is set to ‘Use the following IP address’, and set the IP as shown
below.
• Launch the Nucleus
2
Remote application and check it connects to your
Nucleus
2
as described on Page 21.
Wider Network with a DHCP Server Configuration (Windows)
For connecting Nucleus
2
to a wider network (a multi-studio facility for
example), you will need to configure your computer to Obtain an IP address
automatically in the Properties window.
Both the Nucleus
2
and your computer will then be assigned IP addresses
automatically.
