JEA USER MANUAL
A3+ CMYK
42 I +44 (1753) 214 500
DAY Duty Cycle ON Time Compressor Cycles OFF
The time the evaporator fan is ON when the compressor is OFF and the system is running in Day mode if Fan
Cycle with Compressor (Fd0) is enabled. If 0 is set, the fan will remain on when the compressor if OFF.
DAY Duty Cycle OFF Time Compressor cycles OFF
The time the evaporator fan is OFF when the compressor is OFF and the system is running in Day mode if Fan
Cycle with Compressor (Fd0) is enabled. If 0 is set, the fan will remain on when the compressor if OFF.
NIGHT Duty Cycle ON Time Compressor Cycles OFF
The time the evaporator fan is ON when the compressor is OFF and the system is running in Night mode if Fan
Cycle with Compressor (Fd0) is enabled. If 0 is set, the fan will remain on when the compressor if OFF.
NIGHT Duty Cycle OFF Time Compressor Cycles OFF
The time the evaporator fan is OFF when the compressor is OFF and the system is running in Night mode if Fan
Cycle with Compressor (Fd0) is enabled. If 0 is set, the fan will remain on when the compressor if OFF.
Allow Fan Management During NORMAL Operation
Select whether the evaporator fan cycles with the compressor while in Normal operating mode
No = Fan remains ON when the compressor is OFF
Yes = Fan cycles as regulated by Fd1 & Fd2 (if in Day mode) or Fn1 & Fn2 (if in Night mode)
Allow Fan Management During ECO Mode
Select whether the evaporator fan cycles with the compressor while in Eco operating mode
No = Fan remains ON when the compressor is OFF
Yes = Fan cycles as regulated by Fd1 & Fd2 (if in Day mode) or Fn1 & Fn2 (if in Night mode)
Allow Fan Management During SUPERFROST Mode
Select whether the evaporator fan cycles with the compressor while in Superfrost operating mode
No = Fan remains ON when the compressor is OFF
Yes = Fan cycles as regulated by Fd1 & Fd2 (if in Day mode) or Fn1 & Fn2 (if in Night mode)
Switch OFF Fan On Door Opening Event
Select whether the evaporator fan cycles with the compressor while in Superfrost operating mode
No = Fan remains ON when Door is Open
Yes = Fan turns OFF, respecting Door Open Duration to Switch Fan OFF (d4)
Fan Duty Cycle Override Temperature
The maximum regulation temperature at which the evaporator fan is permitted to cycle. If the override
temperature is exceeded the fan will always be ON until the temperature differential is reached.
Fan Duty Cycle Override Temperature Differential
The temperature differential below the override temperature, which the fan will resume duty cycling
Fan Minimum Stop Time
The Minimum time the fan must be OFF before being allowed to turn back ON
9.12 WINTER MODE (Designed for coolers in sub-zero conditions and a cabinet heater fitted)
PARAMETER DESCRIPTION UNITS MIN MAX DEFAULT
Ht Enable Winter Mode - No / Yes No
HAt Heater Activation Temperature Threshold °C
°F
-40
-40
40
104
-10
14
