12. SPECIFICATION
TEMPERATURE CONTROL
Temperature Control Method Air or Evaporator
Temperature Control Range -50°C to +90°C (-58°F to +194°F)
Temperature Control Modes Day or Night
Normal Mode, Eco Mode, Superfrost Mode
Defrost Control Manual, Timed or Active
Energy Saving Basic Energy Saving - Door tracking to switch between Day and Night mode
or
Self Learning Algorithm - utilising a Matrix of 48 slots over 7 days (columns) operating
pattern
Switches from Day or Night mode automatically to maximise cooler efciency
Advanced Breakout features
Intelligent Time Delay 0 seconds to 5 minutes - maximise compressor availability
Temperature Blind Time 1 to 255 s
Refrigerant Compatibility CO2 & Hydrocarbon
DISPLAY INTERFACE
With Display
Display Type 3 x 7 segment digit, LED display
Digit Height 16.6 mm
Display Colour Red, Yellow, Green, Blue & White
Annunciators Decimal point & 6 x operational status indicators
Compressor, Door, Alarm, Superfrost, Eco mode & Bluetooth
Keypad 4 x Capacitive touch buttons
Up, Down, Back/Superfrost Mode, Tick/Eco Mode
Without Display
Annunciators 3 x operational status indicators
Green Power, Yellow Compressor, Red Alarm
Bezel Colour Customisable colour to match cooler aesthetics
(Not supplied with JEA)
BLUETOOTH AND BATTERY (OPTIONAL)
Bluetooth
Version 4.1 BLE
Connectivity iBeacon, Eddystone & connection to the Sollatek smart device application
Memory On-board storage of approx. 13,000 events
Battery
Type Rechargeable Lithium coin battery
Nominal Voltage 3 V
Capacity 17 mAh
Operating life on one
charge
Approx. 50 days (dependent on the beaconing protocol(s) and frequency requested
INPUT AND OUTPUT
Input Type Temperature Probes, Door Switch, PIR, Humidity Sensor
Temperature Probe Type 10 kΩ NTC (β
25/85
: 3435 K)
Input Connector 1 x 2-way RAST Edge connector and 4 x 3-way RAST Edge connectors
Output Control Compressor, Evaporator fan, Condenser fan, Lights, Defrost heater, Cabinet heater
*Lights and Fan can be powered from a 12 or 24 VDC supply
Relay Rating Control Rating
Compressor Relay 16 A, 250 V 8(6) A, 230 V
Fan Relay 5 A, 250 V 1 (1) A, 230 V
Light Relay 5 A, 250 V 2 (2) A, 230 V
Heater Relay
*
10 A, 250 V 8 A, 230 V
Power / Output Connector Up to 7 x 0.25” (6.35 mm) Fast-on
Data / Interface Connector 8-way connector
