Sollatek JEA Series User Manual

JEA USER MANUAL
A3+ CMYK
54 I +44 (1753) 214 500
VOLTAGE PROTECTION
Powered By External Mains Power
Operating Voltage 90 - 300 VAC
Voltage Protection High and Low voltage disconnect
Immediate Disconnect Voltage 60 / 300 VAC
Low Voltage Blind Time 0 - 255 sec
High Voltage Blind Time 0 - 255 sec
Working Frequency Auto-sense 45/65 Hz
Surge Protection 6.5 kA, <10 ns, 160 J
ENVIRONMENTAL
Ingress Protection IP65 Front for wash-down
Operating Temperature -20°C to +50°C
Operating Humidity 0 - 100%
MECHANICAL SPECIFICATIONS
Mounting 2 options for Panel Mounting:
Front mounting: Screws
Rear mounting: Clips (Not supplied with JEA)
Unit Dimensions 78.0 x 90.0 x 36.5 mm
Unit Weight Approx. 116g depending on model
*
Only present in 4 relay models

Sollatek JEA Series Specifications

General

Brand	Sollatek
Model	JEA Series
Category	Temperature Controller
Language	English
