Electrical connection6
6.1 Connection port description
1
1 LED指示灯
指示逆变器当前的工作状态
Object Description
3
2
DC-switch
Battery Port
4
5
6
7
PV Input
Ai-Dongle
Communication ports
EPS connector
8
Additional grounding screw
AC connector
COM0
BATTERY
LOAD
GRID
ON
OFF
PV1
PV2
PV3
7
8
1 2
3 5
6
4
