Step 2：
gg
and lock the terminal using a wrench.
Step 3： Apply paint to the grounding terminal to ensure corrosion resistance.
6.3 Grid cable connection
6.3.1 Requirements for the grid connection
Cable Requirements
The cable must be dimensioned in accordance with the local and national directives for the
dimensioning of cables. The requirements for the minimum wire size derive from these directives.
   g  g       
gg
U
V
W
A
B
C
D
N
PE
