Description Value
Item
C
D
B
A
External diameter
Copper cable conductor cross-section
Insulation stripping length
12.5…17.5mm
2.5…6mm²
10mm
Sheath stripping length
40mm
Residual current protection
The product is equipped with an integrated universal current-sensitive residual current monitor-
ing unit inside. Hence the product does not require an external residual-current device when
operating.
g
ual-current protection device with a protection limit of not less than 300mA.
Overvoltage category
The inverter can be used in grids of overvoltage category III or lower in accordance with IEC
60664-1. That means that the product can be permanently connected to the grid-connection
gg
reduce overvoltage category IV to overvoltage category III are required.
AC circuit breaker
will prevent residual voltage being present at the corresponding cable after disconnection.
No consumer load should be applied between AC circuit breaker and the inverter.
The selection of the AC circuit breaker rating depends on the wiring design (wire cross-section
ggg
the AC circuit breaker rating may be necessary due to self-heating or if exposed to heat.
The maximum output current and the maximum output overcurrent protection of the inverters
can be found in section 10 “Technical data”.
