Solplanet ASW06kH-T2 - Connecting the Grid Connectors

Complete the installation.
Step 5：Insert the main body into the rubber core and hear the “click” sound.
Step 6：Tighten the nut with an open-ended wrench (torque 2.5±0.5N·m.
click
OK
1
2
6.3.3 Connecting the grid connectors
Step 1：
Remove the dust cover.
UM0035_ASW05-12kH-T2-T3_EN_V01_0523
38
