6.5 DC connection
Requirements for the PV modules per input:
• All PV modules should be of the same type.
• All PV modules should be aligned and tilted identically.
• On the coldest day based on statistical records, the open-circuit voltage of the PV array
must never exceed the maximum input voltage of the inverter.
• The same number of series-connected PV modules must be connected to each string.
• The maximum input current per string must be maintained and must not exceed the through
fault current of the DC connectors.
• The connection cables to the inverter must be equipped with the connectors included in the
scope of delivery.
• The thresholds for the input voltage and the input current of the inverter must be adhered to.
• The positive connection cables of the PV modules must be equipped with the positive DC
connectors. The negative connection cables of the PV modules must be equipped with the
negative DC connectors.
DANGER
！
Danger to life due to electric shock when live components or
DC cables are touched！
When exposed to light, the PV modules generate high DC voltage which is present in the DC
cables. Touching live DC cables results in death or lethal injuries due to electric shock.
• Do not touch non-insulated parts or cables.
• Disconnect the product from voltage sources and ensure it cannot be reconnected before working
on the device.
• Wear suitable personal protective equipment for all work on the product.
6.5.2 Assembling the DC connectors
6.5.1 Requirements for the DC connection
