PIN
The inverter is euied with a communication interace, which is used to connect communica-
tion cables such as lithium battery, electricity meter and arallel machine. The interace congu-
ration o the communication interace is shown in the ollowing gure.
6.8 Communication equipment connection
6.8.1 Communication interface description
USB
RJ45-1 RJ45-3 RJ45-5
RJ45-2 RJ45-6RJ45-4
Terminal-1
Terminal-2
Terminal-3
Terminal-4
Object Description
RJ-45-3
RJ-45-4
Terminal
PI denition
1 2 34 5 6 7
onitor CO2 RS-485A RS-485B GND X X X RS-485A RS-485B
S CO5 X GND X CANAH CANAL X RS-485A RS-485B
8
