Rotating the communication modular will damage the com-
munication modular!
The communication modular is protected by locking nuts to protect the reliability of the
connection. I the body o the communication modular is rotated, the communication
modular will be damaged.
It can only be locked by a nut.
• Do not rotate the communication modular body.
NOTICE
OK
√
×
Complete the installation.
Step 5：
Attach the Ai-Dongle to the connection port in place and tighten it into the port by hand
with the nut in the modular. ake sure the modular is securely connected and the label
on the modular can be seen.
1
2
UM0035_ASW05-12kH-T2-T3_EN_V01_0523
