Step 4：
Remove the dust and waterproof cover of the Ai-Dongle on the inverter and retain it.
Step 2：
Lock the communication cable to the wiring terminal according to the sequence shown
in the ollowing gure.
Step 3：
Insert the wiring terminal into the sealing head, adust the communication cable, insert
the sealing ring, and lock nut.
1
2
3
4
