Table description
Description
Parameter
No.
Act. Power as a
percentage of
PM, Linear
Droop is defined as the active power as a percentage of
P
M.
The active power will continuously move up and down
the voltage characteristic curve in the voltage range of
Ustart to Ustop.
The active power reduce from the PM that is the instanta-
neous active power at the time of exceeding Start voltage
Ustart.
Act. Power as a
percentage of
PN, hysteresis
Act. Power as a
percentage of P
N,
Linear
Act. Power control
for Taiwan
Droop is defined as the active power as a percentage of
PN.
The active power shall remain at or below the lowest
power output level reached in response to the increase in
the voltage range of Ustart to Ustop.
The active power reduce from the rated active power Pn
at all time. The active power maybe don’t reduce if the
limited value of the curve is lower than the instantaneous
active power at the time of exceeding Start voltage Ustart.
Droop is defined as the active power as a percentage of
P
N.
The active power will continuously move up and down the
voltage characteristic curve in the voltage range of Ustart to
Ustop.
The active power reduce from the rated active power Pn
at all time. The active power maybe don’t reduce if the
limited value of the curve is lower than the instantaneous
active power at the time of exceeding Start voltage Ustart.
Special control mode for Chinese Taiwan market.
Act. Power as a
percentage of
PM, hysteresis
Droop is defined as the active power as a percentage of
P
M.
The active power shall remain at or below the lowest
power output level reached in response to the increase in
voltage between Ustart to Ustop.
The active power reduce from the PM that is the
instantaneous active power at the time of exceeding
Start voltage Ustart.
➀
➁
➂
➃
➄
➅
Start voltage
Ustart
The threshold voltage for activating active power
response to overvoltage.
