Table description
Description
Parameter
No.
U/Un
Q/Pn
The voltage as a percentage of UN.
The reactive power as a percentage of Pn.
Phase
Choose the over-excited or under-excited.
Activating power
as a percentage
of P
n
The lock-in active power value that enables the
automatic reactive power delivery mode.
Activation threshold as a percentage of Pn
corresponds to ‘lock-in’ power.
Deactivating
power as a
percentage of P
n
The lock-out active power value that disables
the automatic reactive power delivery mode.
Deactivation threshold as a percentage of Pn
corresponds to ‘lock-out’ power.
Some grid companies maybe requires two active power thresholds as a percentage of Pn to
activate or deactivate the function. The active power thresholds normally call ‘lock-in’ and
‘lock-out’ active power.
➀
➁
➂
➃
➄
