2-8
DSR-2000A/2000AP
VIDEO CONTROL (D-sub 15 pin : MALE)
Pin No. Signal Operating Voltage IN/OUT
1 SYNC CONTROL _5 V to +5 V IN
2 HUE CONTROL _5 V to +5 V IN
3 SC CONTROL _5 V to +5 V IN
4 VIDEO LEVEL CONTROL _5 V to +5 V IN
5 SET UP CONTROL _5 V to +5 V IN
6 CHROMA LEVEL CONTROL _5 V to +5 V IN
7 _9 V SUPPLY _9 V OUT
8 GND
9 FRAME GND
10 ___
11 ___
12 ___
13 Y/C DELAY CONTROL _5 V to +5 V IN
14 __
15 +9 V SUPPLY +9 V OUT
CONTROL PANEL (D-sub 15 pin : FEMALE)
Pin No. Signal Operating Voltage
1SI
2 SCK
3CS
4SO
5 UNREG +12 V
6 UNREG +12 V
7 UNREG +12 V
8 KY EXT
9 GND
10 GND
11 GND
12 GND
13 UNREG GND
14 UNREG GND
15 UNREG GND
34 521
11 1210 9
786
151413
65478
13 121415
213
9
1011
<external view>
<external view>
