101
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN77D
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
RF SENSOR SUB TRANS
CN003 1-784-861-21 CONNECTOR, FFC(LIF(NON-ZIF))9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-551-01 IC SP3723BDAOPM
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-P
Q002 8-729-903-46 TRANSISTOR 2SB1132-P
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/10W
R003 1-216-803-11 METAL CHIP 33 5% 1/10W
R004 1-216-803-11 METAL CHIP 33 5% 1/10W
R005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 METAL CHIP 0 5% 1/10W
R012 1-216-864-11 METAL CHIP 0 5% 1/10W
R013 1-216-864-11 METAL CHIP 0 5% 1/10W
R014 1-216-864-11 METAL CHIP 0 5% 1/10W
R015 1-216-864-11 METAL CHIP 0 5% 1/10W
R016 1-216-864-11 METAL CHIP 0 5% 1/10W
R017 1-216-864-11 METAL CHIP 0 5% 1/10W
R018 1-216-864-11 METAL CHIP 0 5% 1/10W
R019 1-216-864-11 METAL CHIP 0 5% 1/10W
R020 1-216-864-11 METAL CHIP 0 5% 1/10W
R021 1-216-864-11 METAL CHIP 0 5% 1/10W
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 METAL CHIP 0 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/10W
R027 1-216-864-11 METAL CHIP 0 5% 1/10W
R028 1-216-864-11 METAL CHIP 0 5% 1/10W
R029 1-216-864-11 METAL CHIP 0 5% 1/10W
R032 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-864-11 METAL CHIP 0 5% 1/10W
R034 1-219-570-11 METAL CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/10W
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
******************************************************
1-687-132-11 SENSOR BOARD
************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE)3P
******************************************************
A-4749-088-A SUB TRANS BOARD, COMPLETE(E3,E15,SP,MY)
A-4747-641-A SUB TRANS BOARD, COMPLETE (EA)
A-4749-091-A SUB TRANS BOARD, COMPLETE (TH)
***********************
< CAPACITOR >
0C971 1-113-925-11 CERAMIC 0.01uF 20% 250V
C973 1-126-933-11 ELECT 100uF 20% 16V
C975 1-126-767-11 ELECT 1000uF 20% 16V
C976 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C976 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
C977 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C977 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
C978 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C978 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
< CONNECTOR >
CN971 1-568-106-11 PIN, CONNECTOR(3.96mm PITCH)4P
(EXCEPT TH)
CN971 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P(TH)
CN974 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P
CN976 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< DIODE >
D971 8-719-991-33 DIODE 1SS133T-72
D972 8-719-200-82 DIODE 11ES2-NTA1B (TH)
D972 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH)
D973 8-719-200-82 DIODE 11ES2-NTA1B (TH)
D973 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH)
D974 8-719-200-82 DIODE 11ES2-NTA1B (TH)
D974 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH)
D975 8-719-200-82 DIODE 11ES2-NTA1B (TH)
D975 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH)
< IC >
IC971 6-703-546-01 IC TA7804LS
< TRANSISTOR >
Q971 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
R974 1-249-441-11 CARBON 100K 5% 1/4W
R975 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY971 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(EXCEPT TH)
< TRANSFORMER >
0T972 1-437-775-21 TRANSFORMER, POWER (EA)
0T972 1-437-751-12 TRANSFORMER, POWER (EXCEPT EA)
******************************************************
