102
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN77D
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
SURROUND
A-4732-880-A SURROUND BOARD, COMPLETE (EXCEPT TH)
A-4734-255-A SURROUND BOARD, COMPLETE (TH)
***********************
< CAPACITOR >
C301 1-126-963-11 ELECT 4.7uF 20% 50V
C302 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C302 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C303 1-107-473-11 CERAMIC 220PF 5% 50V
C304 1-126-947-11 ELECT 47uF 20% 10V
C306 1-136-495-11 FILM 0.068uF 5% 50V
C307 1-136-495-11 FILM 0.068uF 5% 50V
C308 1-128-576-11 ELECT 100uF 20% 63V
C319 1-162-306-11 CERAMIC 0.01uF 30% 16V
C341 1-126-963-11 ELECT 4.7uF 20% 50V
C342 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C342 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C343 1-107-473-11 CERAMIC 220PF 5% 50V
C344 1-126-947-11 ELECT 47uF 20% 10V
C346 1-136-495-11 FILM 0.068uF 5% 50V
C347 1-136-495-11 FILM 0.068uF 5% 50V
C351 1-126-963-11 ELECT 4.7uF 20% 50V
C352 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C352 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C353 1-107-473-11 CERAMIC 220PF 5% 50V
C354 1-126-947-11 ELECT 47uF 20% 10V
C356 1-136-495-11 FILM 0.068uF 5% 50V
C357 1-136-495-11 FILM 0.068uF 5% 50V
C358 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
CN303 1-564-509-11 PLUG, CONNECTOR 6P
* CN304 1-564-520-11 PLUG, CONNECTOR 5P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-72
D341 8-719-991-33 DIODE 1SS133T-72
D351 8-719-991-33 DIODE 1SS133T-72
D381 8-719-991-33 DIODE 1SS133T-72
D382 8-719-991-33 DIODE 1SS133T-72
D391 8-719-991-33 DIODE 1SS133T-72
< GROUND TERMINAL >
EP301 1-537-738-21 TERMINAL, GROUND
< IC >
IC301 8-749-017-19 IC STK443-050
< TRANSISTOR >
Q301 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q341 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q351 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q381 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q383 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q384 8-729-900-36 TRANSISTOR BA1F4M-TP
Q385 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q386 8-729-900-36 TRANSISTOR BA1F4M-TP
< RESISTOR >
R301 1-249-417-11 CARBON 1K 5% 1/4W F
R302 1-249-437-11 CARBON 47K 5% 1/4W
R303 1-249-413-11 CARBON 470 5% 1/4W
R304 1-249-437-11 CARBON 47K 5% 1/4W
0R305 1-234-499-21 ENCAPSULATED COMPONENT
R307 1-249-417-11 CARBON 1K 5% 1/4W F
R308 1-249-434-11 CARBON 27K 5% 1/4W
R309 1-249-441-11 CARBON 100K 5% 1/4W
R310 1-260-076-11 CARBON 10 5% 1/2W
0R311 1-212-881-11 FUSIBLE 100 5% 1/4W
R319 1-249-429-11 CARBON 10K 5% 1/4W
0R320 1-202-972-61 FUSIBLE 1 5% 1/4W
R331 1-249-437-11 CARBON 47K 5% 1/4W
R332 1-249-438-11 CARBON 56K 5% 1/4W
R333 1-249-439-11 CARBON 68K 5% 1/4W
R341 1-249-417-11 CARBON 1K 5% 1/4W F
R342 1-249-437-11 CARBON 47K 5% 1/4W
R343 1-249-413-11 CARBON 470 5% 1/4W
R344 1-249-437-11 CARBON 47K 5% 1/4W
0R345 1-234-499-21 ENCAPSULATED COMPONENT
R347 1-249-417-11 CARBON 1K 5% 1/4W F
R348 1-249-434-11 CARBON 27K 5% 1/4W
R349 1-249-441-11 CARBON 100K 5% 1/4W
R350 1-260-076-11 CARBON 10 5% 1/2W
R351 1-249-417-11 CARBON 1K 5% 1/4W F
R352 1-249-437-11 CARBON 47K 5% 1/4W
R353 1-249-413-11 CARBON 470 5% 1/4W
R354 1-249-437-11 CARBON 47K 5% 1/4W
0R356 1-234-499-21 ENCAPSULATED COMPONENT
R357 1-249-417-11 CARBON 1K 5% 1/4W F
R358 1-249-434-11 CARBON 27K 5% 1/4W
R359 1-249-441-11 CARBON 100K 5% 1/4W
R360 1-260-076-11 CARBON 10 5% 1/2W
0R361 1-212-881-11 FUSIBLE 100 5% 1/4W
0R387 1-215-889-11 METAL OXIDE 330 5% 2W
0R388 1-215-889-11 METAL OXIDE 330 5% 2W
R390 1-249-429-11 CARBON 10K 5% 1/4W
R395 1-249-429-11 CARBON 10K 5% 1/4W
R396 1-249-433-11 CARBON 22K 5% 1/4W
R397 1-249-417-11 CARBON 1K 5% 1/4W F
R399 1-249-417-11 CARBON 1K 5% 1/4W F
R401 1-249-417-11 CARBON 1K 5% 1/4W F
R402 1-249-433-11 CARBON 22K 5% 1/4W
< RELAY >
RY381 1-755-417-12 RELAY
RY382 1-755-417-12 RELAY
******************************************************
1-687-669-11 SW BOARD
********
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (LEVER)
******************************************************
