Sony HCD-GN77D - Electrical Parts List: DMB03 and Driver Boards; DMB03 Board Resistors, Capacitors, Connectors, Diodes, ICs, Transistors; Driver Board Components

91
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN77D
DMB03
R776 1-216-864-11 METAL CHIP 0 5% 1/10W
R777 1-216-864-11 METAL CHIP 0 5% 1/10W
R778 1-216-845-11 METAL CHIP 100K 5% 1/10W
R780 1-216-864-11 METAL CHIP 0 5% 1/10W
R781 1-216-864-11 METAL CHIP 0 5% 1/10W
R784 1-216-864-11 METAL CHIP 0 5% 1/10W
R785 1-216-833-11 METAL CHIP 10K 5% 1/10W
R786 1-216-845-11 METAL CHIP 100K 5% 1/10W
R787 1-216-845-11 METAL CHIP 100K 5% 1/10W
R788 1-216-845-11 METAL CHIP 100K 5% 1/10W
R789 1-216-845-11 METAL CHIP 100K 5% 1/10W
R799 1-216-864-11 METAL CHIP 0 5% 1/10W
R805 1-216-864-11 METAL CHIP 0 5% 1/10W
R901 1-216-801-11 METAL CHIP 22 5% 1/10W
R902 1-216-801-11 METAL CHIP 22 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/10W
R905 1-216-801-11 METAL CHIP 22 5% 1/10W
R906 1-216-801-11 METAL CHIP 22 5% 1/10W
R907 1-216-801-11 METAL CHIP 22 5% 1/10W
R908 1-216-833-11 METAL CHIP 10K 5% 1/10W
R910 1-216-864-11 METAL CHIP 0 5% 1/10W
R911 1-216-833-11 METAL CHIP 10K 5% 1/10W
R912 1-216-833-11 METAL CHIP 10K 5% 1/10W
R913 1-216-833-11 METAL CHIP 10K 5% 1/10W
R915 1-216-809-11 METAL CHIP 100 5% 1/10W
R916 1-216-821-11 METAL CHIP 1K 5% 1/10W
R917 1-216-821-11 METAL CHIP 1K 5% 1/10W
R918 1-216-801-11 METAL CHIP 22 5% 1/10W
R919 1-216-864-11 METAL CHIP 0 5% 1/10W
R920 1-216-809-11 METAL CHIP 100 5% 1/10W
R921 1-216-809-11 METAL CHIP 100 5% 1/10W
R923 1-216-813-11 METAL CHIP 220 5% 1/10W
R925 1-216-809-11 METAL CHIP 100 5% 1/10W
R926 1-216-809-11 METAL CHIP 100 5% 1/10W
R927 1-216-857-11 METAL CHIP 1M 5% 1/10W
R930 1-216-809-11 METAL CHIP 100 5% 1/10W
R931 1-216-801-11 METAL CHIP 22 5% 1/10W
R932 1-216-801-11 METAL CHIP 22 5% 1/10W
R933 1-216-801-11 METAL CHIP 22 5% 1/10W
R935 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R940 1-216-809-11 METAL CHIP 100 5% 1/10W
R942 1-216-809-11 METAL CHIP 100 5% 1/10W
R943 1-216-809-11 METAL CHIP 100 5% 1/10W
R947 1-216-864-11 METAL CHIP 0 5% 1/10W
R948 1-216-864-11 METAL CHIP 0 5% 1/10W
R949 1-216-864-11 METAL CHIP 0 5% 1/10W
R958 1-216-801-11 METAL CHIP 22 5% 1/10W
R962 1-216-833-11 METAL CHIP 10K 5% 1/10W
R964 1-216-833-11 METAL CHIP 10K 5% 1/10W
R970 1-216-864-11 METAL CHIP 0 5% 1/10W
R971 1-216-864-11 METAL CHIP 0 5% 1/10W
R973 1-216-864-11 METAL CHIP 0 5% 1/10W
R974 1-216-864-11 METAL CHIP 0 5% 1/10W
R975 1-216-833-11 METAL CHIP 10K 5% 1/10W
R976 1-216-864-11 METAL CHIP 0 5% 1/10W
R978 1-216-833-11 METAL CHIP 10K 5% 1/10W
R984 1-216-833-11 METAL CHIP 10K 5% 1/10W
R988 1-216-864-11 METAL CHIP 0 5% 1/10W
R990 1-216-864-11 METAL CHIP 0 5% 1/10W
R991 1-216-864-11 METAL CHIP 0 5% 1/10W
R992 1-216-864-11 METAL CHIP 0 5% 1/10W
R994 1-216-864-11 METAL CHIP 0 5% 1/10W
R995 1-216-864-11 METAL CHIP 0 5% 1/10W
R996 1-216-864-11 METAL CHIP 0 5% 1/10W
R997 1-216-864-11 METAL CHIP 0 5% 1/10W
R998 1-216-864-11 METAL CHIP 0 5% 1/10W
R1000 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1001 1-216-864-11 METAL CHIP 0 5% 1/10W
R1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R1201 1-216-864-11 METAL CHIP 0
R1202 1-216-864-11 METAL CHIP 0
R1301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R1303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R1801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R1802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R1803 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R9980 1-216-864-11 METAL CHIP 0 5% 1/10W
R9981 1-216-864-11 METAL CHIP 0 5% 1/10W
R9986 1-216-864-11 METAL CHIP 0 5% 1/10W
R9987 1-216-864-11 METAL CHIP 0 5% 1/10W
R9988 1-216-864-11 METAL CHIP 0 5% 1/10W
R9993 1-216-864-11 METAL CHIP 0 5% 1/10W
R9994 1-216-864-11 METAL CHIP 0 5% 1/10W
R9998 1-216-864-11 METAL CHIP 0 5% 1/10W
R9999 1-216-864-11 METAL CHIP 0 5% 1/10W
< NETWORK RESISTOR >
RB10 1-233-388-11 RES, NETWORK 68 (3216)
RB11 1-233-388-11 RES, NETWORK 68 (3216)
RB12 1-233-388-11 RES, NETWORK 68 (3216)
RB13 1-233-388-11 RES, NETWORK 68 (3216)
RB14 1-233-388-11 RES, NETWORK 68 (3216)
RB15 1-233-388-11 RES, NETWORK 68 (3216)
RB16 1-233-388-11 RES, NETWORK 68 (3216)
RB17 1-233-388-11 RES, NETWORK 68 (3216)
RB18 1-234-524-21 RES, CHIP NETWORK 33
RB19 1-234-524-21 RES, CHIP NETWORK 33
RB20 1-234-524-21 RES, CHIP NETWORK 33
RB21 1-234-524-21 RES, CHIP NETWORK 33
RB202 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB203 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB204 1-234-523-21 RES, CHIP NETWORK 0 (3216)
< VIBRATOR >
X901 1-781-945-21 VIBRATOR, CERAMIC (20MHz)
X902 1-795-630-11 VIBRATOR, CRYSTAL (27MHz)
******************************************************
1-687-135-11 DRIVER BOARD
***********
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-164-159-11 CERAMIC 0.1uF 50V
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 30% 16V
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
