92
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN77D
GAME INDRIVER
< CONNECTOR >
CN701 1-785-338-11 PIN, CONNECTOR(LIGHT ANGLE)12P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRNSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W F
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W F
R712 1-249-425-11 CARBON 4.7K 5% 1/4W F
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W F
R722 1-249-425-11 CARBON 4.7K 5% 1/4W F
R723 1-249-425-11 CARBON 4.7K 5% 1/4W F
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W F
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W F
******************************************************
A-4732-871-A GAME IN BOARD, COMPLETE (EXCEPT TH)
A-4734-533-A GAME IN BOARD, COMPLETE (TH)
*********************
< CAPACITOR >
C604 1-124-257-00 ELECT 2.2uF 20% 50V
C606 1-124-257-00 ELECT 2.2uF 20% 50V
C630 1-162-294-31 CERAMIC 0.001uF 10% 50V
C631 1-162-294-31 CERAMIC 0.001uF 10% 50V
C634 1-162-294-31 CERAMIC 0.001uF 10% 50V
C635 1-162-294-31 CERAMIC 0.001uF 10% 50V
C715 1-162-215-31 CERAMIC 47PF 5% 50V
C716 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C716 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
C717 1-124-584-00 ELECT 100uF 20% 10V
C718 1-124-584-00 ELECT 100uF 20% 10V
C719 1-124-257-00 ELECT 2.2uF 20% 50V
C721 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C722 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C723 1-126-160-11 ELECT 1uF 20% 50V
C724 1-136-495-11 FILM 0.068uF 5% 50V
C725 1-124-464-11 ELECT 0.22uF 20% 50V
C726 1-124-464-11 ELECT 0.22uF 20% 50V
C727 1-136-155-00 FILM 0.015uF 5% 50V
C728 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C729 1-126-160-11 ELECT 1uF 20% 50V
C730 1-161-494-00 CERAMIC 0.022uF 25V
C731 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C732 1-136-495-11 FILM 0.068uF 5% 50V
C733 1-124-589-11 ELECT 47uF 20% 16V
C734 1-124-589-11 ELECT 47uF 20% 16V
C735 1-124-257-00 ELECT 2.2uF 20% 50V
C736 1-124-261-00 ELECT 10uF 20% 50V
C737 1-124-261-00 ELECT 10uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C740 1-162-282-31 CERAMIC 100PF 10% 50V
C741 1-124-250-11 ELECT 0.15uF 20% 50V
C742 1-162-215-31 CERAMIC 47PF 5% 50V
C743 1-162-290-31 CERAMIC 470PF 10% 50V
C744 1-162-294-31 CERAMIC 0.001uF 10% 50V
C747 1-124-257-00 ELECT 2.2uF 20% 50V
C748 1-161-494-00 CERAMIC 0.022uF 25V
C749 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C749 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
< CONNECTOR >
* CN606 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
< DIODE >
D705 8-719-109-85 DIODE MTZJ-T-72-5.1B
< GROUND TERMINAL >
EP701 1-537-738-21 TERMINAL, GROUND
EP703 1-537-738-21 TERMINAL, GROUND
< IC >
IC721 8-759-450-96 IC M65850P
IC722 8-759-167-88 IC NJM4565D
< JACK >
J601 1-764-592-11 JACK 3P (GAME INPUT)
J631 1-794-702-11 JACK, HEADPHONE (PHONES)
J721 1-817-630-11 JACK (LARGE TYPE) (MIC)
< TRANSISTOR >
Q721 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-249-417-11 CARBON 1K 5% 1/4W F
R604 1-249-441-11 CARBON 100K 5% 1/4W
R605 1-249-441-11 CARBON 100K 5% 1/4W
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-432-11 CARBON 18K 5% 1/4W
R723 1-249-431-11 CARBON 15K 5% 1/4W
R724 1-249-431-11 CARBON 15K 5% 1/4W
R725 1-249-431-11 CARBON 15K 5% 1/4W
R726 1-249-437-11 CARBON 47K 5% 1/4W
R727 1-249-431-11 CARBON 15K 5% 1/4W
R728 1-249-431-11 CARBON 15K 5% 1/4W
R729 1-249-431-11 CARBON 15K 5% 1/4W
R730 1-249-431-11 CARBON 15K 5% 1/4W
R731 1-247-881-00 CARBON 120K 5% 1/4W
