Sony HCD-MD555 - Over Light Head (HR901); MD Optical Pick-Up Block (KMS-260 A;J1 N)

— 32 —
2 Over light hea
d
(HR901)
1 Screw (+P1.7 × 2.5)
1 Screw (M 1.7 × 1.4)
2 Stopper
4 Optical pick-up block (KMS-260A/JIN)
Remove the optical pickup block in the
direction of the arrow.
3 Shaft (MAIN)
4-13. OVER LIGHT HEAD (HR901)
4-14. MD OPTICAL PICK-UP BLOCK (KMS-260A/J1N)
