6-24. PRINTED WIRING BOARDS – DRIVER SECTION – • See page 19 for Circuit Boards Location.
Ref. No. Location
D701 E-1
IC701 E-1
IC711 B-5
• Semiconductor
Location
There are a few cases that the part isn’t mounted
in model is printed on diagram.
(Page 30)
