9
HCD-VX777
2-8. LEAF SW BOARD, HEAD (A) BOARD, HEAD (B) BOARD
2-9. BASE UNIT
4
screw (+PTT 2
×
4),
ground point
6
screw (+PTT 2
×
4),
ground point
2
LEAF SW board
1
five claws
5
HEAD (A) board
7
HEAD (B) board
3
Remove the four solderings.
5
3
two screws (+PTPWH M2.6), floating
9
two springs (insulator), coil
7
two springs (insulator),
coil
0
two insulators (BU-30)
qa
base unit
8
two insulators
(BU-30)
6
two stoppers (BU)
2
screw (DIA. 12), floating
1
flat type wire (CN101)
4
two screws
(+BVTP 2.6
×
8)
