70
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
MAINHEAD (A) HEAD (B) LEAF SW
1-676-220-11 HEAD (A) BOARD
*************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD (B) BOARD
*************
< CONNECTOR >
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
**********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119-25
< IC >
IC1001 8-749-016-76 IC RPI-321
IC1002 8-749-016-76 IC RPI-321
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY)(DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-536-12 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-536-12 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1008 1-771-536-12 SWITCH, LEAF (DECK B 120/70)
S1009 1-771-536-12 SWITCH, LEAF (DECK B REC)
**************************************************************
A-2007-984-A MAIN BOARD, COMPLETE (EA)
************************
A-4726-198-A MAIN BOARD, COMPLETE (TH)
************************
A-4476-138-A MAIN BOARD, COMPLETE (E,SP)
**************************
A-4476-618-A MAIN BOARD, COMPLETE (IA)
************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C1 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C3 1-104-664-11 ELECT 47uF 20.00% 16V
C4 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C7 1-216-864-91 SHORT 0
C11 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C12 1-104-664-11 ELECT 47uF 20.00% 16V
C13 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C14 1-162-974-11 CERAMIC CHIP 3PF 50V
C15 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C16 1-104-664-11 ELECT 47uF 20.00% 16V
C17 1-126-959-11 ELECT 0.47uF 20.00% 50V
C18 1-126-960-11 ELECT 1uF 20.00% 50V
C19 1-126-960-11 ELECT 1uF 20.00% 50V
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C21 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C22 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C23 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C24 1-126-963-11 ELECT 4.7uF 20.00% 50V
C25 1-126-964-11 ELECT 10uF 20.00% 50V
C26 1-164-471-11 CERAMIC CHIP 820PF 5.00% 50V
C27 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C28 1-126-963-11 ELECT 10uF 20.00% 50V
C29 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C30 1-126-962-11 ELECT 3.3uF 20.00% 50V
C31 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C32 1-126-963-11 ELECT 4.7uF 20.00% 50V
C34 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
(E,EA,SP,IA)
C35 1-104-664-11 ELECT 47uF 20.00% 16V
(E,EA,SP,TH)
C36 1-126-963-11 ELECT 4.7uF 20.00% 50V
C38 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
(E,EA,SP,IA)
C39 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C40 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C41 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C42 1-162-940-11 CERAMIC CHIP 9PF 0.5PF 50V
(E,EA,SP,IA)
C42 1-162-941-11 CERAMIC CHIP 10PF 0.5PF 50V(TH)
C43 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C46 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C51 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C52 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C53 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C55 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
