83
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
R315 1-218-285-11 RES-CHIP 75 5% 1/16W
R316 1-218-285-11 RES-CHIP 75 5% 1/16W
R317 1-218-285-11 RES-CHIP 75 5% 1/16W
R319 1-211-990-11 METAL CHIP 75 0.5% 1/16W
R403 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R404 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R501 1-216-809-11 METAL CHIP 100 5% 1/16W
R502 1-216-809-11 METAL CHIP 100 5% 1/16W
R503 1-216-809-11 METAL CHIP 100 5% 1/16W
R504 1-216-809-11 METAL CHIP 100 5% 1/16W
R505 1-216-809-11 METAL CHIP 100 5% 1/16W
R506 1-216-809-11 METAL CHIP 100 5% 1/16W
R507 1-216-833-11 METAL CHIP 10K 5% 1/16W
R508 1-216-833-11 METAL CHIP 10K 5% 1/16W
R511 1-216-833-11 METAL CHIP 10K 5% 1/16W
R512 1-216-833-11 METAL CHIP 10K 5% 1/16W
R513 1-216-833-11 METAL CHIP 10K 5% 1/16W
R516 1-216-833-11 METAL CHIP 10K 5% 1/16W
R517 1-216-833-11 METAL CHIP 10K 5% 1/16W
R518 1-216-833-11 METAL CHIP 10K 5% 1/16W
R519 1-216-809-11 METAL CHIP 100 5% 1/16W
R520 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R521 1-216-833-11 METAL CHIP 10K 5% 1/16W
R523 1-216-803-11 METAL CHIP 33 5% 1/16W
R524 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R526 1-216-849-11 METAL CHIP 220K 5% 1/16W
R528 1-216-845-11 METAL CHIP 100K 5% 1/16W
R530 1-216-809-11 METAL CHIP 100 5% 1/16W
R531 1-216-809-11 METAL CHIP 100 5% 1/16W
R532 1-216-864-91 SHORT 0
R533 1-216-864-91 SHORT 0
R534 1-216-833-11 METAL CHIP 10K 5% 1/16W
R535 1-216-833-11 METAL CHIP 10K 5% 1/16W
R536 1-216-813-11 METAL CHIP 220 5% 1/16W
R537 1-216-809-11 METAL CHIP 100 5% 1/16W
R538 1-216-833-11 METAL CHIP 10K 5% 1/16W
R539 1-216-864-91 SHORT 0
R540 1-216-864-91 SHORT 0
R542 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R543 1-218-881-11 METAL CHIP 27K 0.5% 1/16W
R544 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R545 1-216-809-11 METAL CHIP 100 5% 1/16W
R546 1-216-821-11 METAL CHIP 1K 5% 1/16W
R548 1-216-821-11 METAL CHIP 1K 5% 1/16W
R549 1-216-809-11 METAL CHIP 100 5% 1/16W
R550 1-216-809-11 METAL CHIP 100 5% 1/16W
R551 1-216-809-11 METAL CHIP 100 5% 1/16W
R552 1-216-809-11 METAL CHIP 100 5% 1/16W
R555 1-216-857-11 METAL CHIP 1M 5% 1/16W
R556 1-216-809-11 METAL CHIP 100 5% 1/16W
R557 1-216-809-11 METAL CHIP 100 5% 1/16W
R560 1-218-849-11 METAL CHIP 1.2K 0.5% 1/16W
R561 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R562 1-216-833-11 METAL CHIP 10K 5% 1/16W
R564 1-216-837-11 METAL CHIP 22K 5% 1/16W
R577 1-216-837-11 METAL CHIP 22K 5% 1/16W
R578 1-216-837-11 METAL CHIP 22K 5% 1/16W
R579 1-216-833-11 METAL CHIP 10K 5% 1/16W
R580 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VIBRATOR >
X501 1-781-155-21 VIBRATOR, CERAMIC
X503 1-767-519-11 VIBRATOR
**************************************************************
MISCELLANEOUS
***************
0F971 1-532-325-00 FUSE, GLASS TUBE (DIA.5) (6.3A/250V)
(EXCEPT TH)
0F974 1-532-325-00 FUSE, GLASS TUBE (DIA.5) (6.3A/250V)
0F975 1-532-325-00 FUSE, GLASS TUBE (DIA.5) (6.3A/250V)
0F976 1-533-949-31 TIME LUG (DIA.5) (T8A/250V)
0F977 1-533-949-31 TIME LUG (DIA.5) (T8A/250V)
0T901 1-435-861-11 TRANSFORMER, POWER (TH)
0T901 1-435-866-11 TRANSFORMER, POWER (E,EA,SP,IA)
155 1-454-887-32 SOLENOID, PLUNGER
0109 1-569-008-21 ADAPTOR, CONVERSION
104 1-690-589-31 WIRE (FLAT TYPE)(13 CORE)
305 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
M961 1-763-072-11 FAN, D.C.
102 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
0108 1-777-071-51 CORD, POWER (E,EA,SP,IA)
0108 1-791-901-11 CORD, POWER (TH)
259 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-476-500-11 COMMANDER, STANDARD (RM-SV230)
1-501-374-11 ANTENNA, LOOP
1-501-659-71 ANTENNA (FM)
1-751-619-11 CORD, CONNECTION
4-210-254-01 CUSHION (FOOT)
4-232-033-01 COVER BATTERY (FOR RM-SV230)
4-232-651-11 INSTRUCTION MANUAL (ENGLISH)
4-232-651-21 INSTRUCTION MANUAL (SPANISH)
4-232-651-31 INSTRUCTION MANUAL (FRENCH)
4-232-651-41 INSTRUCTION MANUAL (CHINESE)
4-232-651-51 INSTRUCTION MANUAL (ARABIC)
4-232-651-61 INSTRUCTION MANUAL (PERSIAN)
4-232-651-81 INSTRUCTION MANUAL (PERSIAN)
4-972-322-01 FOOT (Y)
*************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-881-09 SCREW +BVTT 4X8 (S)
#5 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#6 7-623-921-01 RING,RETAINING, CAPSTAN
#7 7-685-781-09 SCREW +PTT 2X4 (S)
VIDEO
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
