Sony HT-CT500 - Specifications

100
GB
• Remove any obstacles in the path between
the remote and the front panel display.
• Replace both batteries in the remote with
new ones, if they are weak.
• Make sure you select the correct input on the
remote.
The volume turns down when the output
method changes from the TV speaker to the
system speaker.
• The Volume Limit function is working. For
details, see “Using the Volume Limit
function” (page 61).
If the system still does not
operate properly after performing
the above measures, reset the
system as follows:
Use the buttons on the subwoofer for this
operation.
1 Press ?/1 to turn on the power.
2 Press INPUT SELECTOR, VOLUME –,
?/1 at the same time.
“COLD RESET” appears and the system is
reset. The system menu, sound field, etc.,
return to the default settings.
Formats supported by this
system
Digital input formats supported by this system
are as follows.
* Linear PCM accepts sampling frequencies of no
more than 48 kHz.
Amplifier section
Power output (rated)
Front L / Front R: 80 W + 80 W
(at 4 ohms, 1 kHz, 1 %
THD)
Power output (reference)
RMS output power
Front L / Front R: 100 W/ch (per channel at 4
ohms, 1 kHz, 10 % THD)
Center*: 100 W (at 4 ohms, 1 kHz,
10 % THD)
Subwoofer: 100 W (at 4 ohms, 100 Hz,
10 % THD)
* Depending on the sound field settings and the source,
there may be no sound output.
Inputs (Analog)
TV, VIDEO 1 Sensitivity: 550 mV
Impedance: 33 kohms
Inputs (Digital)
TV, VIDEO 2 Optical
VIDEO 3 Coaxial, optical
Specifications
Format Supported/Not supported
Dolby Digital a
DTS a
Linear PCM (2ch)* a
Linear PCM (5.1ch,
7.1ch)* (Only on
HDMI)
a
Dolby Digital Plus ×
Dolby True HD ×
DTS-HD ×
