Sony ICP-X1224

521
TimelineRewind Region ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
User1 to User8
DME1 to DME4
Device1 to Device12
PBus
GPI
Current
Region
• “Current” = currently selected region
TimelineFF Region ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
User1 to User8
DME1 to DME4
Device1 to Device12
PBus
GPI
Current
Region
• “Current” = currently selected region
Shotbox Register 1 to 99 Register number
Pause Time 0 to 999 Pause time (number of frames)
StartTC Device 1 to 12
FrameMemory1Clip to
Fr
ameMemory16Clip
ClipPlayer1 to ClipPlayer4
Device
• “1 to 12” = device 1 to 12
RouterXpt
DestinationButton 1 to 128 Destination selection delegation button
number
Source 1 to 9999 Source number
Level 1 to 8 Level number
PatternLimit ME ME1 to ME5, PP Switcher bank
Status ToOn, ToOff, Any Enable/disable pattern limit
• “ToOn” = enable
• “ToOff” = disable
• “Any” = enabled/disable switching
TransitionType ME ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
ME1Main&Sub to ME5Main&Sub,
PPM
ain&Sub
Switcher bank
TransitionType Mix
NAM
SuperMix
PresetColorMix
Wipe
DMEWipe
FM1&2Clip to FM15&16Clip
Transition type
KeyTransitionType ME ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
ME1Main&Sub to ME5Main&Sub,
PPM
ain&Sub
Switcher bank
Key Key1 to Key8 Key
Direction On, Off, Any Key on/off
•“On” = on
• “Off” = off
• “Any” = on/off switching
KeyTransitionType Mix
Wipe
DMEWipe
Transition type
Symbol Parameter Parameter setting values Description
