Sony ICP-X1224

522
NextTransition ME ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
ME1Main&Sub to ME5Main&Sub,
PPM
ain&Sub
Switcher bank
All On, Off Next transition
KeyPriority On, Off Next transition
BKGD On, Off Next transition
Key1 to Key8 On, Off Next transition
FadeToBlack Time Current
0 to 999
Transition rate (number of frames)
• “Current” = current value
TLDirectionNormal Region ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
User1 to User8
DME1 to DME4
Device1 to Device12
PBus
GPI
Current
Region
• “Current” = currently selected region
TLDirectionReverse Region ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
User1 to User8
DME1 to DME4
Device1 to Device12
PBus
GPI
Current
Region
• “Current” = currently selected region
TLNormalReverseOn Region ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
User1 to User8
DME1 to DME4
Device1 to Device12
PBus
GPI
Current
Region
• “Current” = currently selected region
TLNormalReverseOff Region ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
User1 to User8
DME1 to DME4
Device1 to Device12
PBus
GPI
Current
Region
• “Current” = currently selected region
UtilityButton UtilityModule UtilityBox Utility/shotbox control block or utility control
bl
ock
Button 1 to 480 Button number
• ICP-X1000 series utility control block: 1 to
30
0
UtilityStatus On, Off
Current
Utility function on/off
•“On” = on
• “Off” = off
• “Current” = current status
Rewind Device 1 to 12
FrameMemory1Clip to
Fr
ameMemory16Clip
ClipPlayer1 to ClipPlayer4
Device
• “1 to 12” = device 1 to 12
FF Device 1 to 12
FrameMemory1Clip to
Fr
ameMemory16Clip
ClipPlayer1 to ClipPlayer4
Device
• “1 to 12” = device 1 to 12
Symbol Parameter Parameter setting values Description
