ClipRecall Device FM1 to FM16
ClipPlayer1 to ClipPlayer4
Device
ClipType Pair, Single Image content type
ClipFilePath Clip File Path Folder path and content name of image
co
ntent
(folder name and content name delimited by
sl
ash (/) characters)
Audio Device FM1 to FM16
ClipPlayer1 to ClipPlayer4
Device
AudioMode On, Off Enable/disable audio
FMLoop Device FM1 to FM16
ClipPlayer1 to ClipPlayer4
Device
FMLoopMode On, Off Enable/disable loop
KeyBusUtilButton ME ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
ME1Main&Sub to ME5Main&Sub,
PPM
ain&Sub
Switcher bank
Bank 1 to 10 Bank number
KeyBusButton 1 to 36 Button number
• ICP-X1000 series cross-point control
bl
ock: 1 to 24
UtilityStatus On, Off
Current
Utility function on/off
•“On” = on
• “Off” = off
• “Current” = current status
DeviceRecord Device 1 to 12 Device
AuxMix AuxMixBus Aux1, Aux3, … Aux47 Odd-numbered AUX bus
AuxMixStatus On, Off Enable/disable AUX mix
XptPadPage MEAuxBank ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
1stAux, 2ndAux
Switcher bank or AUX bus control block
Page 1 to 14 Cross-point pad page
XptRowAssign MEBank ME1 to ME5, PP
ME1Sub to ME5Sub, PPSub
Switcher bank
Row 1st, 2nd, 3rd, 4th Button row
BusFunction A, B
Key1 to Key8
Key1Source to Key8Source
Utility1, Utility2
DMEExternalVideo
DMEUtility1, DMEUtility2
EditPreview
Aux1 to Aux48
FrameMemory1, FrameMemory2
DME1Video to DME4Video
DME1Key to DME4Key
UtilShotbox1 to UtilShotbox10
Bus or bank
GPITestFire Box DCU Fixed setting for GPI operation
Port 1 to 50 GPI output port number
NetworkMessaging Device 1 to 12 Device
Command Command
Command (up to 23 characters)
Symbol Parameter Parameter setting values Description
