– 34 –
KP-44PS2/44PS2U/51PS2
RM-903
• Device Register Setting b EXT. Deflection
EXT. Deflection
No Descr. Def. Min Max Data
1 Linearity 127 0 255 127
2 H Centre 31 0 63 31
3 H Trap 31 0 63 31
4 Rotation 0 0 255 0
5 FocusPhase 127 0 255 127
Select : v V Last menu : b Enter Item : B
• Device Register Setting b Deflection
Deflection
No Descr. Def. Min Max Data
1 V-Size 31 0 63 34
2 V-Position 31 0 63 36
3 V-Comp 1 0 3 1
4 V-Linear 7 0 15 7
5 S-Corr 7 0 15 7
6 H-Size 31 0 63 51
7 Ew-Dc OFF OFF ON OFF
8 Pin-Amp 31 0 63 31
9 Up-CPin 31 0 63 31
10 M-Pin 2 0 3 2
11 Lo-CPin 31 0 63 31
12 Trapezium 7 0 15 7
13 H-Position 31 0 63 47
14 AFC-Bow 7 0 15 7
15 AFC-Angle 7 0 15 7
16 Up-Vlin 0 0 15 0
17 Lo-Vlin 0 0 15 0
18 MPIP PAmp –5 –10 10 –5
19 MPIP UCPin 0 –10 10 0
20 MPIP LCPin 0 –10 10 0
21 MPIP Trap 0 –10 10 0
22 EPG PAmp –3 –10 10 –3
23 EPG UCPin 0 –10 10 0
24 EPG LCPin 1 –10 10 1
25 EPG Trap 0 –10 10 0
Select : v V Last menu : b Enter Item : B
• Device Register Setting b Dynamic Convergence
Dynamic Convergence
No Descr. Def. Min Max Data
1 Range 63 0 63 63
2 H stat 33 0 63 33
3 H amp l 37 0 63 37
4 H amp r 36 0 63 36
5 Up Y 31 0 63 31
6 Low Y 33 0 63 33
7 Y up l 30 0 63 30
8 Y up r 30 0 63 30
9 Y low l 31 0 63 31
10 Y low r 30 0 63 30
11 Mbow up l 31 0 63 31
12 Mbow up r 32 0 63 32
13 Mbow low l 32 0 63 32
14 Mbow low r 32 0 63 32
15 V stat 32 0 63 32
16 TCorPCtrl OFF OFF ON OFF
17 TopCorPin 31 0 63 31
18 BCorPCtrl OFF OFF ON OFF
19 BotCorPin 31 0 63 31
Select : v V Last menu : b Enter Item : B
• Device Register Setting b Colour Decoder 1
Colour Decoder 1
No Descr. Def. Min Max Data
1 TINT 31 0 63 31
2 SUB COLOUR 7 0 15 7
3 SUB CONTR 7 0 15 7
4 SHARP GAIN 8 0 15 8
5 Y-OUT LEV. 50 0 63 40
6 C-OUT LEV. 50 0 63 45
7 Y-DL 8 0 10 3
8 Cr OFF. 1 7 0 15 7
9 Cb OFF. 1 7 0 15 7
10 Cr OFF. 2 7 0 15 7
11 Cb OFF. 2 7 0 15 7
12 V CD FREQ 3 0 7 3
13 V CD MODE 1 0 3 1
14 MVM OFF OFF ON OFF
15 S R-Y ADJ 7 0 15 7
16 S B-Y ADJ 2 0 15 5
17 BELL/HPF 2 0 3 2
18 BELL F0 OFF OFF ON OFF
19 S GP 0 0 3 0
Select : v V Last menu : b Enter Item : B
