Sony KP-44PS2 - Page 35

– 35 –
KP-44PS2/44PS2U/51PS2
RM-903
• Device Register Setting b Colour Decoder 2
Colour Decoder 2
No Descr. Def. Min Max Data
1 TINT 31 0 63 31
2 SUB COLOUR 7 0 15 7
3 SUB CONTR 7 0 15 7
4 SHARP GAIN 8 0 15 8
5 Y-OUT LEV. 50 0 63 31
6 C-OUT LEV. 50 0 63 45
7 Y-DL 8 0 10 3
8 Cr OFF. 1 7 0 15 7
9 Cb OFF. 1 7 0 15 7
10 Cr OFF. 2 7 0 15 7
11 Cb OFF. 2 7 0 15 7
12 V CD FREQ 3 0 7 3
13 V CD MODE 1 0 3 1
14 MVM OFF OFF ON OFF
15 S R-Y ADJ 7 0 15 7
16 S B-Y ADJ 2 0 15 5
17 BELL/HPF 2 0 3 2
18 BELL F0 OFF OFF ON OFF
19 S GP 0 0 3 0
Select : v V Last menu : b Enter Item : B
• Device Register Setting b MID-X
MID-X
No Descr. Def. Min Max Data
1 M H POS 0 –31 31 0
2 S H POS 0 –8 8 0
3 D YS SEL 1 0 3 1
4 D YS DELAY 7 0 7 7
5 D SYNC MOD ON OFF ON ON
6 Text Sharp OFF OFF ON OFF
Select : v V Last menu : b Enter Item : B
• Device Register Setting b External PLL MID-X
External PLL MID-X
No Descr. Def. Min Max Data
1 VCO7-0PAL 184 0 255 184
2 VCO7-0NTSC 172 0 255 172
3 VCO11-8 6 0 15 6
4 DIV1, 2, 4, 8 2 0 3 2
5 Fine Delay 0 0 63 0
6 Coar. Delay 0 0 3 0
7 Ch. Pump 0 0 3 0
8 PD Pol. ON OFF ON ON
9 DSync Wdth 3 0 3 3
10 Dsync Del OFF OFF ON OFF
11 Sync Pol ON OFF ON ON
12 DSync Pol ON OFF ON ON
13 Clk En ON OFF ON ON
14 NClk En OFF OFF ON OFF
15 Clk/2 En OFF OFF ON OFF
16 NClk/2 En OFF OFF ON OFF
17 DSync En ON OFF ON ON
18 Unlock En OFF OFF ON OFF
19 VCO Bypass ON OFF ON ON
20 Synth Pwr ON OFF ON ON
21 Rdout Pwr OFF OFF ON OFF
22 DIVOUT En ON OFF ON ON
23 DSync Byp OFF OFF ON OFF
24 DSync Hold OFF OFF ON OFF
Select : v V Last menu : b Enter Item : B
• Device Register Setting b Panorama Chip
Panorama Chip
No Descr. Def. Min Max Data
1 ROM speed 25 0 255 25
2 Prog. No. 0 0 11 3
3 HSize Offs 3 0 15 3
4 IMODE 0 0 255 0
5 Disable OFF OFF ON OFF
6 Send AUX OFF OFF ON OFF
7 AUX0 67 0 255 67
8 AUX1 0 0 255 0
9 AUX2 68 0 255 68
10 AUX3 0 0 255 0
11 AUX4 12 0 255 12
12 AUX5 81 0 255 81
13 AUX6 7 0 255 7
14 AUX7 0 0 255 0
15 AUX8 65 0 255 65
16 AUX9 244 0 255 244
17 AUX10 32 0 255 32
18 AUX11 209 0 255 209
19 AUX12 7 0 255 7
20 AUX13 0 0 255 0
Select : v V Last menu : b Enter Item : B
