Sony MHC-V83D - Cdm90-Dvbu204;;M

MHC-V83D
17
Sony CONFIDENTIAL
For Authorized Servicer
2-7. CDM90-DVBU204//M
1 four screws
(+BVTP 3 u 8)
6 CDM90-DVBU204//M
4 Draw two wires out of
the hole in CDM bracket section.
5 Draw wire out of
the hole in CDM
bracket section.
7 CDM bracket section
2 cushion, saranet
(30 u 50)
3 core, ferrite
SYSSET
2020/06/2222:32:42(GMT+09:00)
