Sony MHC-V83D - SMPS Board Section

MHC-V83D
57
Sony CONFIDENTIAL
For Authorized Servicer
#1
101
101
102
chassis section
mid horn
rear-H section
ns
B
C
101
B
C
7-3. SMPS BOARD SECTION
101 267783901 +PWH 3X8 (SUMITITE)
0 102 A5009900A SMPS MOUNTED PC BOARD
#1 768564671 SCREW +BVTP 3X8 TYPE2 IT-3
ns not supplied
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SYSSET
