2-9. CHASSIS SECTION
– Rear view –
B
B
C
C
:LUHVHWWLQJ
filament
tape
wire
CN8507 (4P)
wire
CN8504 (10P)
wire CN8510
(5P)
LED HUB
board
front side
:LUHVHWWLQJ
rear side
qa Draw out the wire
from the hole.
hole
chassis
qd four screws
(+BVTP 3 u 8)
1 filament
tape
3 filament
tape
2 CN8504
(10P)
4 CN8510 (5P)
5 CN8507 (4P)
6 CN8511 (4P)
7 CN2005 (4P)
8 CN3502 (2P)
0 CN6000 (2P)
9 flexible flat cable
(11 core) (CN9500)
qg chassis
section
qf
qs Remove the wire
from clamp (N)
rear side
:LUHVHWWLQJ
MOTHERBOARD
board
SYSSET
