2-6. LENS BLOCK
[LENS BLOCK CHECK SERVICE POSITION]
FC-67
DD-119
FC-67
DD-119
a
1 Screws (M2 × 4), lock ace, P2
2 Remove
the claws
3 ZM block
flexible board
4 Cabinet (VP) assembly
5 Screw (M2 × 3)
6 Screw (M2 × 4),
lock ace, P2
7 Remove the claw
8 Cabinet (LT)
9 SW block (side sw)
flexible board
0 Tapping screw
(B2
× 5)
!¡
Plate (A)
fixed
!™ Screws (M2 × 4),
lock ace, P2
!£ Cabinet (LB) assembly
Remove gently the cabinet (LB)
assembly in the direction of the
arrow
a .
!¢ Two screws (M2 × 4),
lock ace, P2
!∞ Two screws (M2 × 4),
lock ace, P2
!§ Two screws
(M2
× 4),
lock ace, P2
!¶ Remove the claws
Remove the claws
gradually because
the flexible wire
can be cut if it is
removed at once.
!• Cable (4P)
!ª SW block (side sw)
flexible board (10P)
Be careful that the
board is very short.
@º Screw
(M2
× 3)
@¡ Tapping screw
(B2
× 5)
@™ SW block
(side sw)
@£ Cabinet (front)
assembly
@¶ FP-67 flexible
board (16P)
@§ Flexible board
(from lens block)
@∞ Screws
(M2
× 3)
@¢ Screw (M2 × 3)
Screw
@• Lens block assembly
SW block (side sw)
ZM block (front sw)
Cabinet (VP) assembly
LENS block
Extension cable
(J-6082-357-A)
Cabinet (front) assembly
Battery cable (4P)
CN301 (DD-119 board)
AC IN
AC
ADAPTOR
Be careful that it can
be easily caught.
