5-19
14. CCD Defect Compensation
Subject Clear chart
(40 cm from the front of the protection
glass)
Adjustment Page E
Adjustment Address C2 to D5
Note 1: Check that there are no dust, no dirt and no reflection on the clear
chart.
Note 2: Any subject other than the clear chart should not be in the screen.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Check that the data of page: E, address: C2 to D5 is “00”. If
not, change the data to “00”, and press the PAUSE button.
3) Turn the power of the unit OFF and then ON.
4) Wait until the camera picture appear on the LCD screen.
5) Select page: 0, address: 01, and set data: 01.
6) Select page: E, address: 11, set data: 56, and press the PAUSE
button of the adjustment remote commander.
7) Select page: E, address: C0, set data: 14, and press the PAUSE
button.
8) Select page: 2, address: 01, set data: 8D, and press the PAUSE
button.
(When the compensation data is take in, the data will be
automatically input to page: F, address: C2 to D5.)
9) Select page: 2, address: 02, and check that the data is “01”.
Processing after Completing Adjustments
1) Select page: E, address: 11, set data: 18, and press the PAUSE
button.
2) Select page: 0, address: 01, and set data: 00.
3) Select page: 2, address: 01, and set data: 00, and press the
PAUSE button of the adjustment remote commander.
15. CCD Defect Compensation Check
Subject Clear chart
(40 cm from the front of the protection
glass)
Measurement Point Display data of page : 3, address : FF
Measuring Instrument Adjustment remote commander
Specified Value 00
Note 1: Check that there are no dust, no dirt and no reflection on the clear
chart.
Note 2: Any subject other than the clear chart should not be in the screen.
Note 3: This adjustment should be carried out upon completion of “14.
CCD Defect Compensation”.
Adjusting method:
1) Turn the power of the unit OFF and then ON.
2) Wait until the camera picture appear on the LCD screen.
3) Select page: 0, address: 01, and set data: 01.
4) Select page: E, address: 11, set data: 56, and press the PAUSE
button of the adjustment remote commander.
5) Select page: 3, address: FA, and set data: 45.
6) Select page: 2, address: 01, set data: 89, and press the PAUSE
button.
7) Select page: 3, address: 4C, and check that the data changed to
“01”.
8) Select page: 3, address: FF, and check that the data is “00”.
Note: If the data of page: 3, address: FF is “01” to “0F”, the CCD
defect compensation is defective.
Processing after Completing Adjustments
1) Select page: E, address: 11, set data: 18, and press the PAUSE
button.
2) Select page: 0, address: 01, and set data: 00.
3) Select page: 2, address: 01, and set data: 00, and press the
PAUSE button of the adjustment remote commander.
To Next Page
