6-7
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
CND : Canadian model
CN : Chinese model
AUS : Australian model
JE : Tourist model
HK : Hong Kong model
CD-207 DD-119
Be sure to read “Note on the CCD imager replacement” on
page 4-8 when changing the CCD Imager.
A-7073-745-A CD-207 BOARD, COMPLETE
**********************
(Ref.No.:2,000 Series)
(IC401 is not included in this complete board)
< CAPACITOR >
C401 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C404 1-113-981-11 TANTAL. CHIP 22uF 20% 20V
C405 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
C406 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN401 1-766-346-21 CONNECTOR, FFC/FPC 16P
< IC >
IC401 A-7030-955-A CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L401 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q401 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R401 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R402 1-216-809-11 METAL CHIP 100 5% 1/16W
R403 1-216-809-11 METAL CHIP 100 5% 1/16W
R404 1-216-857-11 METAL CHIP 1M 5% 1/16W
R405 1-216-864-11 METAL CHIP 0 5% 1/16W
R406 1-216-295-91 SHORT 0
************************************************************
A-7073-746-A DD-119 (110) BOARD, COMPLETE
****************************
(Ref.No.:2,000 Series)
< CAPACITOR >
C302 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C303 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C306 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C309 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C310 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C311 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C314 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C315 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C316 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C318 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C319 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C320 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C321 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C322 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C323 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C324 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C325 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C326 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C327 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C328 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C329 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C330 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C331 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C332 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C333 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C334 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C335 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C336 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C337 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C338 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C339 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C340 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C342 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C343 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C344 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C345 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C346 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C347 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C348 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C349 1-164-337-11 CERAMIC CHIP 2.2uF 16V
C350 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C352 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C353 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C354 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C357 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C358 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C359 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
